INVT Goodrive300-01A Series Operation Manual page 78

Goodrive300-01A series VFD for air compressor
Function
Name
code
Switching
P13.04 frequency of
pull-in current
High-frequency
superposing
P13.05
frequency
(reserved)
High--frequency
P13.06 superposing
voltage
Control
P13.08
parameter 1
Control
P13.09
parameter 2
Maladjustment
P13.11
detection time
High-frequency
P13.12 compensation
coefficient
Short-circuit
P13.13
braking current
Hold time of
P13.14 short-circuit
braking for start
Hold time of
P13.15 short-circuit
braking for stop
Description
0.00Hz–P00.03 (max. output frequency)
200Hz–1000Hz
0.0–300.0% (of the rated voltage of the
motor)
0–FFFF
0–300.00
The function code is used to adjust the
responsiveness of
function. If the load inertia is large, increase
the value of P13.11 properly, however, the
responsiveness may slow down accordingly.
Setting range: 0.0–10.0s
The function code is valid when the motor
speed exceeds the rated speed. If motor
oscillation occurred, adjust this parameter
properly.
Setting range: 0.0–100.0%
0.0–150.0% (VFD)
0.00–50.00s
0.00–50.00s
-72-
anti-maladjustment
Function description
Default Modify
○
30.00Hz
◎
500Hz
◎
40.0%
○
0x120
○
5.00
○
0.5s
○
50.0%
○
0.0%
○
0.00
○
0.00
