Goodrive300-01A series VFD for air compressor
Product model
GD300-01A-132G-4-E
GD300-01A-160G-4-E
GD300-01A-185G-4-E
GD300-01A-200G-4-E
GD300-01A-220G-4-E
GD300-01A-250G-4-E
GD300-01A-280G-4-E
GD300-01A-315G-4-E
GD300-01A-350G-4-E
GD300-01A-400G-4-E
GD300-01A-500G-4-E
A.9 Product weight and package dimensions of 520V–660V VFDs
For VFDs of AC 3PH 520V (-15%)–660V (+10%)
Product model
GD300-01A-022G-6-E
GD300-01A-030G-6-E
GD300-01A-037G-6-E
GD300-01A-045G-6-E
GD300-01A-055G-6-E
GD300-01A-075G-6-E
GD300-01A-090G-6-E
GD300-01A-110G-6-E
GD300-01A-132G-6-E
GD300-01A-160G-6-E
GD300-01A-185G-6-E
GD300-01A-200G-6-E
GD300-01A-220G-6-E
GD300-01A-250G-6-E
GD300-01A-280G-6-E
GD300-01A-315G-6-E
GD300-01A-350G-6-E
GD300-01A-400G-6-E
GD300-01A-500G-6-E
GD300-01A-630G-6-E
N/W (kg) G/W (kg)
76.0
76.0
76.0
76.0
135
135
135
137
137
410
410
N/W (kg) G/W (kg)
30
30
30
30
47
47
47
47
47
85
85
85
85
135
135
137
137
410
410
410
-121-
Product dimensions
Package dimension
97.0 971x631x565
97.0 971x631x565
97.0 971x631x565
97.0 971x631x565
165 1086x826x595
165 1086x826x595
165 1086x826x595
167 1086x826x595
167 1086x826x595
450 1850x840x820
450 1850x840x820
Package dimension
33 695x410x470
33 695x410x470
33 695x410x470
33 695x410x470
58 760x445x580
58 760x445x580
58 760x445x580
58 760x445x580
58 760x445x580
112 971x631x565
112 971x631x565
112 971x631x565
112 971x631x565
165 1086x826x595
165 1086x826x595
167 1086x826x595
167 1086x826x595
450 1850x840x820
450 1850x840x820
450 1850x840x820
(mm)
(mm)
