INVT Goodrive300-01A Series Operation Manual page 168

Goodrive300-01A series VFD for air compressor
Category
Electrical
performance
Environment
requirement
Mechanical
performance
Function
Ethernet
USB port
Program download
method
Serial
communication port
Viewing angle of
LCD
(T/B/L/R)
Rated power
Rated voltage
Power supply
protection
Allowed power
outage
CE & RoHS
Working
temperature
Storage
temperature
UV resistance
Ambient humidity 10–90%RH (no condensation)
Shock resistance 10–25Hz (X, Y, Z direction 2G/30 minutes)
Cooling method
Ingress protection
rating
Mechanical
structure
Cut-out dimensions 192mm×138mm
Overall dimensions 204mm×145mm×33.8mm
Overall weight
None
1 USB Slave 2.0 port; 1 USB Host 2.0 port
USB Slave/U disk
COM1：RS232/RS485/RS422
COM2: RS485
COM3: RS232
50'/70'/70'/70'
< 10W
DC24V, allowable working range DC 9V–28V
Surge protection capability
< 5ms
Compliant with EN61000-6-2:2005 and
EN61000-6-4:2007
Compliant with RoHS lightning surge ±1kV, group pulse
±2kV
Static contact 4kV, air discharge 8kV
0–50℃
-20–60℃
Disallowed to work under strong UV (such as direct
sunlight)
Natural air cooling
The front panel reaches IP65 (installed with a flat panel
cabinet), and the rear shell of the device reaches IP20.
Engineering plastic
About 560g
