Goodrive300-01A series VFD for air compressor
Function
Name
code
RO6
P06.23 switch-off
delay
RO4
P06.27 switch-on
delay
RO4
P06.28 switch-off
delay
AO1 analog
P06.29 output type
selection

P07 group HMI

Function
Name
code
P07.00 User password
Function
P07.01
parameter copy
Description
0.000–50.000s
0.000–50.000s
0.000–50.000s
0: Voltage
1: Current
Note: When switching the AO1 analog output
type, it is necessary to ensure that the
position of AO1 jumper cap on the main
control board is correct. In addition, you need
to modify P06.29, otherwise deviation may
occur in the accuracy of the AO1 analog
output.
Description
0–65535
0: No operation
1: Uploading function parameters from the
machine to keypad
2: Downloading function parameters
(including the motor parameters) from the
keypad to machine
3: Downloading function parameters
(excluding motor parameters of the P02 and
P12 groups) from the keypad to machine
4: Downloading function parameters (only
motor parameters of the P02 and P12
groups) from the keypad to machine
Note: After the parameter is set to 1, 2, 3 or
4, and the operation is executed, the
parameter is automatically restored to 0.
-55-
Function description
Default Modify
○
0.000s
○
0.000s
○
0.000s
○
0
Default Modify
○
0
◎
0
