P21 group Power-frequency fan protection

Function
Name
code
Rated current
P21.00
of the fan
Current
P21.01 transformation
ratio of the fan
Description
BIT8: Changing and discharging water to
medium water level
BIT9: Changing and replenishing water to
medium water level
BIT10: Changing and replenishing water to
high water level
BIT11: Changing and discharging water to low
water level
BIT12: Flag bit for water heating
BIT13: Flag bit for abnormal water level
BIT14: Water replenishing delay alarm
BIT15: Water discharging delay alarm
-20–150℃
-20–150℃
-20–150℃
Description
0.0–40.0A
This function code is related to current
detection and overload protection function of
power-frequency fan. If P21.00 is set to a
non-zero value, this function is enabled. If
P21.00 is set to 0, this function is disabled.
1.0–4000.0
-91-
Function description
Default Modify
5
○
20
○
0
○
Default Modify
○
0.0A
200
(≤15kW);
○
1000
(≥18.5kW)
