Goodrive300-01A series VFD for air compressor
Function
Name
code
Overmodulation
P08.41
selection
Keypad data
P08.42
control setting
Description
modulation
1: PWM mode 2, 3PH modulation
LED tens: PWM low-speed carrier limit
0: Low-speed carrier limit mode 1
1: Low-speed carrier limit mode 2
2: No limit
LED hundreds: Reserved
0x00–0x11
LED ones:
0: Disable overmodulation
1: Enable overmodulation
LED tens:
0: Mild overmodulation
1: Deepened overmodulation
0x000–0x1223
LED ones: Frequency enabling selection
0: Both ∧/∨ key and digital potentiometer
adjustments are valid
1: Only ∧/∨ keys adjustment is valid
2: Only digital potentiometer adjustment is
valid
3: Neither ∧/∨ key nor digital potentiometer
adjustment are valid
LED tens: Frequency control selection
0: Valid only when P00.06=0
1: Valid for all frequency setting methods
2: Invalid for multi-step speed running when
multi-step speed running has the priority
LED hundreds: Action selection for stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a stop
command is received
LED thousands: ∧/∨ keys and digital
potentiometer integral function
0: The integral function is valid
1: The integral function is invalid
-64-
Function description
Default Modify
◎
01
○
0x000
