INVT Goodrive300-01A Series Operation Manual page 100

Goodrive300-01A series VFD for air compressor
Function
Name
code
User-defined
P25.01 fault action
selection 2
User-defined
P25.02 fault action
selection 3
User-defined
P25.03 fault action
selection 4
User-defined
P25.04 fault action
selection 5
User-defined
P25.05 fault action
selection 6
User-defined
P25.06 fault action
selection 7
User-defined
P25.07 fault action
selection 8
Description
0–0x6666
Ones: Overcurrent at deceleration (OC2)
Tens: Overcurrent at constant speed (OC3)
Hundreds: Overvoltage at acceleration (OV1)
Thousands: Overvoltage
(OV2)
0–0x6666
Ones: Overvoltage at constant speed (OV3)
Tens: Bus undervoltage fault (UV)
Hundreds: Motor overload (OL1)
Thousands: VFD overload (OL2)
0–0x6666
Ones: Phase loss on input side (SPI)
Tens: Phase loss on output side (SPO)
Hundreds: Reserved
Thousands: Inverter
(OH2)
0–0x6666
Ones: External fault (EF)
Tens: RS485 communication fault (CE)
Hundreds: Current detection fault (ItE)
Thousands: Motor autotuning fault (tE)
0–0x6666
Ones: EEPROM operation fault (EEP)
Tens: PID feedback sensor offline (PIDE)
Hundreds: Reserved
Thousands: Running time reached (END)
0–0x6666
Ones: Electronic overload (OL3)
Tens: Reserved
Hundreds: Reserved
Thousands place: Reserved
0–0x6666
Ones: Reserved
Tens: Input overvoltage (IOV)
Hundreds: Input undervoltage (IUV)
Thousands: To-ground short circuit fault 1
(ETH1)
-94-
at deceleration
module overheating
Function description
Default Modify
○
0x0000
○
0x0020
○
0x0002
○
0x0020
○
0x0020
○
0x0002
○
0x0220
