Goodrive300-01A series VFD for air compressor
Category
temperature input
Installation mode
Ingress protection
Others
Function
Analog
Analog output
Digital input
Digital output
485
communication
Temperature of
running
environment
rating
Pollution degree
Cooling mode
DC reactor
EMC filter
1 input (standard): PTA1/PTB1
1 input (optional): PTA2/PTB2
Resolution: 1℃
Range: -20℃～150℃
Accuracy error: 3℃
1 output (standard): AO1/GND
0–10V/0–20mA
3 inputs (standard): S1, S2, S3
5 inputs (optional): S4, S5, S6, S7, S8
Common terminal: COM
Max. frequency: 1kHz
2 outputs (standard): RO1A/RO1C, RO2A/RO2B/RO2C
4 inputs (optional): RO3A, RO4A, RO5A, RO6A, ROC
Contact capacity: 3A/AC250V, 1A/DC30V
1 channel (standard): 485+/485-
Shielding layer grounding PE/CGND
Wall installation, flange installation
-10–+50° C; derating
temperature exceeds 40° C; derate by 1% for every
increased 1° C
IP20
Degree 2
Forced air cooling
DC reactors are optional parts for 7.5–11kW VFD models
and can be built into the models;
DC reactors have been built into 15–110kW VFD models
as standard configuration; DC reactors are optional
parts for 132–315kW VFD models (AC 380V) and can be
externally connected.
C3 filters have been built into the VFDs as standard
configuration. ECM filter is set to be invalid by default, if it
is necessary to enable it, you can manually plug the
jumper cap in the socket marked J10.
