Goodrive300-01A series VFD for air compressor
B.2.4.6 User parameter interface
1. Enter the user parameter interface through the main menu.
User parameter
Set temperature
Fan stop temperature
Fan startup
03.17 16:02:35
Set pressure
Unloading pressure
Loading pressure
Setting Temp
Fan Starting Temp
Fan Stopping Temp
Return
03.17 16:02:35
Loading Delay
Stop Delay
No-load Delay
Restart Delay
Sleep Function
Load/Unload Mode
Return
03.17 16:02:35
Restart Delay
Sleep Function
Load/Unload Mode
Power consumption
Accumlated Run Time
Timing switch setting
Return
Figure B-15 User parameter interface
Initial value
Constant exhaust temperature that is set for constant
75℃
temperature control on fan.
When the exhaust temperature is lower than this value, the
65℃
fan is stopped.
75℃ When the exhaust temperature is higher than this value, the
User param
xxx.xx Mpa
xxx.xx Mpa
xxx.xx Mpa
xxxxxx
xxxxxx
xxxxxx
Home
User param
xxxxxx s
xxxxxx s
xxxxxx s
xxxxxx s
Enable
Automatic
Home
User param
xxxxxx s
Enable
Automatic
xxxx.x kW.h
xxxxxx h
Home
Function
