Goodrive300-01A series VFD for air compressor
Figure 3-19 Main circuit terminal diagram for 660V 250–350kW VFD models
Figure 3-20 Main circuit terminal diagram for 660V 400–630kW VFD models
Table 3-3 Screw specification and torque of main circuit terminals
Power range (kW)
22–45
55–132
160–220
250–350
A1 A2
R S
POWER
U
T
(+)
P1
V
W
MOTOR
Terminal screw
specification
M6
M8
M12
M12
-19-
Wiring instruction
(-)
Torque of torque driver
·
(N m)
3.5
10
35
35
