INVT Goodrive300-01A Series Operation Manual page 15

Goodrive300-01A series VFD for air compressor
Rated values of AC 3PH 380V(-15%)–240V(+10%) VFDs
Model
GD300-01A-7R5G-4-E
GD300-01A-011G-4-E
GD300-01A-015G-4-E
GD300-01A-018G-4-E
GD300-01A-022G-4-E
GD300-01A-030G-4-E
GD300-01A-037G-4-E
GD300-01A-045G-4-E
GD300-01A-055G-4-E
GD300-01A-075G-4-E
GD300-01A-090G-4-E
GD300-01A-110G-4-E
GD300-01A-132G-4-E
GD300-01A-160G-4-E
GD300-01A-185G-4-E
GD300-01A-200G-4-E
GD300-01A-220G-4-E
GD300-01A-250G-4-E
GD300-01A-280G-4-E
GD300-01A-315G-4-E
GD300-01A-350G-4-E
GD300-01A-400G-4-E
GD300-01A-500G-4-E
Note:

Rated input current is the actually measured result under 380V input voltage. Input current of
7.5–11kW and 132–315kW VFD models is the actually measured results in cases where there
is no DC reactor. Input current of 15–110kW VFD models is the actually measured result in
cases where there is DC reactor. Input current of 350–500kW VFD models is the actually
measured result under 380V input voltage with input reactor.

Rated output current is defined as the output current under 380V output voltage.

Under the allowable input voltage range, the output current shall not exceed its rated output
current, and the output power also shall not exceed its rated output power.
Output power
(kW)
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
185
200
220
250
280
315
350
400
500
-9-
Input current Output current
(A)
25
32
32
37
44
58
72
87
106
140
170
202
265
310
345
385
430
485
545
610
625
715
890
Product overview
(A)
18.5
25
32
38
45
60
75
92
115
150
180
215
260
305
340
380
425
480
530
600
650
720
860
