Goodrive300-01A series VFD for air compressor
Fault
Fault type
code
EEPROM
EEP
operation error
PID feedback
PIDE
offline fault
Running time
END
reached
Electronic
OL3
overload fault
IOV
Input overvoltage
IUV
Input undervoltage
To-ground
ETH1
short-circuit fault 1
Possible cause
• Motor parameters are set
improperly.
• The deviation between the
parameters obtained from
autotuning and the
standard parameter is
huge.
• Autotuning timeout.
• Error occurred to the
writing/reading of control
parameters.
• EEPROM damaged.
• PID feedback offline.
• PID feedback source
disappears
The actual running time of the
VFD is larger than the
internally set time.
The VFD reports overload
pre-alarm according to the
set value.
Input grid overvoltage.
Input overvoltage threshold
(P18.46) is set improperly.
Input grid undervoltage.
Input undervoltage threshold
(P18.47) is not set improperly.
• VFD output is short
circuited to ground.
• Current detection circuit is
-104-
Fault information and fault handling
Solution
nameplate parameters
correctly.
• Empty the motor load and
identify again.
• Check the motor wiring and
parameter setup.
• Check whether upper limit
frequency is larger than 2/3
of the rated frequency.
• Press STOP/RST to reset.
• Replace the main control
board.
• Check PID feedback signal
wire.
• Check PID feedback source
• Ask supplier for help.
• Adjust the set running time.
Check the load and overload
pre-alarm threshold.
• Check the input grid power
supply.
• Check the installation and
wiring.
• Ensure the setting value of
P18.46 is proper.
• Check the input grid power
supply.
• Check the installation and
wiring.
• Ensure the setting value of
P18.47 is proper.
• Check whether motor wiring
is normal/motor is short
circuited to ground.
