INVT Goodrive300-01A Series Operation Manual page 42

Goodrive300-01A series VFD for air compressor
Function
Name
code
Setting channel
P00.06 of A frequency
command
Setting channel
P00.07 of B frequency
command
Reference
object of B
P00.08
frequency
command
Combination
P00.09 mode of setting
source
Frequency set
P00.10
through keypad
P00.11 ACC time 1
P00.12 DEC time 1
Running
P00.13
direction
Carrier
P00.14 frequency
setting
Description
0: Keypad
1: Analog P1-
2: Reserved
3: Analog P2-
4: Reserved
5: Reserved
6: Multi-step speed running
7: PID control
8: Modbus communication
9–11: Reserved
Note: A frequency and B frequency cannot
use the same frequency reference mode. You
can set the frequency source through P00.09.
0: Max. output frequency
1: A frequency command
0: A
1: B
2: (A+B)
3: (A- B)
4: Max(A, B)
5: Min. (A, B)
0.00 Hz–P00.03 (max. output frequency)
0.0–3600.0s
0.0–3600.0s
0: Run at the default direction.
1: Run at the opposite direction.
2: Disable reverse running
1.0–8.0kHz
-36-
Function description
Default Modify
○
0
○
2
○
0
○
0
○
50.00Hz
Model
○
depended
Model
○
depended
○
2
Model
○
depended
