INVT Goodrive300-01A Series Operation Manual page 178

Goodrive300-01A series VFD for air compressor
Function
description
Address
definition
forward rotating (0–Fmax (unit: 0.01Hz))
The set value of upper limit frequency of
2006H
reverse rotating (0–Fmax (unit: 0.01Hz))
Upper limit torque of electromotion torque
2007H (0–3000, 1000 corresponds to 100.0% of
motor current of the VFD)
Upper limit torque of brake torque
2008H 3000, 1000 corresponds to 100.0% of
rated motor current)
Special control command word:
Bit0–1: =00: Motor 1
Bit2: =1 Torque control =0: Speed control
Bit3: =1 Power consumption cleared to
2009H
zero =0: Power consumption not cleared to
zero
Bit4: =1 Pre-excitation =0: Pre-excitation
forbidden
Bit5: =1 DC brake =0: DC brake forbidden
Virtual input terminal command, range:
200AH
0x000–0x1FF
Virtual output terminal command, range:
200BH
0x00–0x0F
The set voltage value (used for V/F
separation)
200CH
(0–1000, 1000 corresponds to 100.0%
rated motor voltage)
The set value 1 of AO output (-1000–1000,
200DH
1000 corresponds to 100.0%)
The set value 2 of AO output (-1000–1000,
200EH
1000 corresponds to 100.0%)
BIT0: =1 running time of part 1 cleared to
BIT1: =1 running time of part 2 cleared to
200FH
BIT2: =1 running time of part 3 cleared to
Data meaning
=01: Motor 2
=10: Motor 3 =11: Motor 4
zero; =0: invalid
zero =0: invalid
zero =0: invalid
-172-
Communication protocol
R/W
characteristics
R/W
R/W
(0–
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
