Goodrive300-01A series VFD for air compressor
Category
Note:
1. Only single VFD integrated machine supports power-frequency fan output and 220V/110V power
output, for example, GD300-01A-7R5G-4-CT, GD300-01A-011G-4-CT, and
GD300-01A-015G-4-CT.
2. When the input voltage exceeds 440VAC, the power-frequency transformer inside the single VFD
integrated machine will need to be customized.

2.2 Product nameplate

Note: This is an example of the standard model. CE, TUV, and IP20 are marked according to the
actual certification condition.

2.3 Model description

The model code contains product information. Users can find the model code on the VFD nameplate
or simple nameplate.
Sign Description
○
Abbreviation of product series Goodrive300-01A: GD300-01A VFD for air compressor
1
○
Power class
2
○
3
Load type
○
Voltage class
4
Power-frequency fan/
○
5
Built-in transformer
Function
Figure 2-1 Product nameplate
GD300-01A – 015 G – 4 -CT
①
Figure 2-2 Product model
015: 15kW
G: Constant torque load
4: AC 3PH 380V(-15%)–440V(+10%)
No character: VFD dedicated for single-VFD air
compressor
Single-VFD air compressor integrated machine
C: Built-in contactor units, supports power-frequency fan
output
Specification
position of J10).
Users can choose the optional external filter
which fulfills the requirements of IEC61800-3
C2.
③ ④
②
Content
-6-
Product overview
⑤
