Goodrive300-01A series VFD for air compressor
clock can work properly even after power failure.
Table B-3 Ordering description for the RS485 communication LCD keypad
Item
RS485
communication
LCD keypad
Name
①
Status
②
indicator
③
④
⑤
⑥
Keys
⑦
Description
KEY-LCD01-Z 11022–00141
Table B-4 LCD keypad description
RUN
TRIP
QUICK/JOG
Function key
Shortcut key
Order No.
Includes a 2.5-meter RS485 keypad
cable, a 2.5-meter emergency stop
cable, a keypad installation bracket,
and a CR2032 lithium button battery.
Description
VFD running status indicator.
LED on: in running state
LED off: in stopped state
LED blinking: in parameter autotuning state
Fault indicator.
LED on: in fault state
LED off: in normal state
LED blinking: in pre-alarm state
Shortcut key indicator, which displays different
states under different functions. See the
definition of QUICK/JOG for details.
The function of a function key varies with the
menu and is displayed at the bottom of the
display area.
Re-definable. It is defined as JOG function by
default, namely jogging. The function of the
shortcut key can be set through the ones place of
P07.02:
0: No function
1: Jog (linked with indicator ③, logic: steady on)
2: Switch display status using the shifting key
3: Switch between FWD/REV running (linked
with indicator ③, logic: steady off)
4: Clear the UP/DOWN setting (linked with
-128-
External optional accessories
Remarks
