Goodrive300-01A series VFD for air compressor
Function
Name
code
Function of
P07.02
QUICK/JOG
Sequence of
switching
P07.03 running-command
channels by
pressing QUICK
Stop function
P07.04 selection of
STOP/RST
Selection 1 of
parameters
P07.05
displayed in
running state
Description
0: No function
1: Jogging
2: Switch display status through the shifting
key
3: Forward/reverse running switching
4: Clear the setting of UP/DOWN
5: Coast to stop
6: Switch running-command giving methods
in sequence
7: Quick debugging mode (non-factory
parameter debugging)
0: Keypad→Terminal→Communication
1: Keypad←→Terminal
2: Keypad←→Communication
3: Keypad←→Communication
0: Valid only for keypad control
1: Valid both for keypad and terminal control
2: Valid both for keypad and communication
control
3: Valid for all control modes
0x0000–0xFFFF
BIT0: Running frequency (Hz on)
BIT1: Set frequency (Hz blinks)
BIT2: Bus voltage (V on)
BIT3: Output voltage (V on)
BIT4: Output current (A on)
BIT5: Running rotating speed (rpm on)
BIT6: Output power (% on)
BIT7: Output torque (% on)
BIT8: PID reference value (% blinks)
BIT9: PID feedback value (% on)
BIT10: Input terminal state
BIT11: Output terminal state
BIT12: Torque setting value (% on)
BIT13–BIT15: Reserved
-56-
Function description
Default Modify
◎
1
○
0
○
0
○
0x03FF
