Goodrive300-01A series VFD for air compressor
Category
PT100 signal
input
Pressure signal
input
Digital
input/output
S3 / PTC
Analog input
Communication
Sign Name
24V reference
0V
ground
Analog
PTA1
temperature
PTB1
signal 1
P1+
Analog pressure
signal 1
P1-
S1 Digital input 1
S2 Digital input 2
Digital input 3
Motor
overtemperature
protection
AO1
Analog input
GND
485+
RS485
communication
485-
Terminal function
screen.
You can select 24V output or 24V and 1.1Ω resistor
series connection output through the jumper J11. By
default, 24V output is selected in factory.
24V reference ground
1. Resolution: 1° C
2. Range: -20° C–150° C
3. Detection precision: 3° C
1. Input range: current/voltage is optional, 4–
20mA/2–10V corresponds to 0–1.6MPa; of which P1
is switched via the jumper J8, and the default is input
current signal.
2. Input impedance: 30kΩ during voltage input;
500Ω during current input
3. Resolution: 5mV (minimum value)
4. Error: ± 1%, 25° C
1. Internal impedance: 3.3kΩ
2. 12–30V voltage input is acceptable
3. Max. input frequency: 1kHz
You can select internal power (NPN mode) or
external power (PNP mode) through the jumper J9.
The default is internal power (NPN mode).
1. Internal impedance: 3.3kΩ
2. 12–30V voltage input is acceptable
3. Max. input frequency: 1kHz
This channel circuit uses internal power (NPN
mode).
External PTC temperature switch signal input, PTC
resistance acts at 2.3kΩ.
1. Output range: 0–10V voltage or 0–20mA current;
voltage or current output is switched via the jumper
J2. The default is current type.
2. Error: ± 1%, 25° C
Analog ground
485 communication terminal, adopting the Modbus
protocol
