Goodrive300-01A series VFD for air compressor
Function
Name
code
Digital input
P05.11
filter time
Virtual
P05.12 terminal
setting
Terminal
P05.13
control mode
S1 switch-on
P05.14
delay
S1 switch-off
P05.15
delay
S2 switch-on
P05.16
delay
S2 switch-off
P05.17
delay
S3/PTC
P05.18 terminal
switch-on delay
S3/PTC
P05.19 terminal
switch-off delay
S4 switch-on
P05.20
delay
S4 switch-off
P05.21
delay
S5 switch-on
P05.22
delay
S5 switch-off
P05.23
delay
S6 switch-on
P05.24
delay
S6 switch-off
P05.25
delay
Description
Setting range: 0x00 –0xFF
0.000–1.000s
0: Virtual terminals are invalid
1: Modbus communication virtual terminals
are valid
2–4: Reserved
0: 2-wire control 1
1: 2-wire control 2
2: 3-wire control 1
3: 3-wire control 2
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
