Figure 21-149 Axis Value of Joint

Please confirm with jog operation of simulator on 3D monitor

The movement can be confirmed by entering the axis value only on the user mech. edit screen.

To move the user mech. on the 3D monitor, specify the mechanism on the simulation operation

panel and operate the jog.
