11.7.4.23. Collapsing command blocks
When the program being edited contains a command block or a procedure, blocks can be displayed in an
easier-to-view format as "
state or expand state by clicking
All command blocks and procedures are displayed in a collapsed state by clicking the [Edit] tab -> [Command line]
group -> [Collapse all] button on the ribbon.
All command blocks and procedures are displayed in an expand state by clicking the [Edit] tab ->
[Command line] group -> [Expand all] button on the ribbon.
11-162
" (expand state) or " " (collapsed state). The display can be changed to a collapsed
or button.
Click button
Click button
Procedure
Command block
Figure 11-59 Collapsed Display of Command Blocks
