6. After
all
the necessary parameters have
been entered for a specific device, enter
. the following command to proceed with
initialization.
K.GO.
If there are remaining devices waiting to
be initialized, steps 4 through 6 of this
procedure are repeated for each device.
TRAINxx,y.
Assigns or changes print train identification y of
line printer defined by EST ordinal xx. This
command can set the identification if it was not
specified in the EQ entry of the CMRDECK, or
change an
identificati~n
previously included in the
CMRDECK. An LR designation in the EQ entry
indicates a 580-12 line printer, LS is a 580-16 line
printer, and LT is a 580-20 line printer. LP is
applicable to all line printer
types~
Print trains
supported for the 580 printers are 596-1 and
596-5. The y field specifies the print train.
1.
Print Train
1 596-1 (for CDC graphic 64-character
set files); default.
2
3
4
5
6
7
Reserved for future use.
t
Reserved for future use.
t
596-5 (for ASCII graphic 64-character
set files).
596-5 (for ASCII graphic 64-character
set files).
'596-6 (for ASCII graphic 95-character
set files).
596-6 (to print ASCII graphic
64-character set files as on a 596-5).
BATCHIO EQUIPMENT COMMANDS
The following commands are valid only if the BATCHIO
subsystem is currently assigned to a control point. The
BATCHIO subsystem controls the local batch peripheral
devices (card readers, card punches, and line printers).
Current activity of BATCHIO equipment can be monitored
on the BATCHIO
(I)
display. Refer to section 4 for
information concerning the I display.
BKSPxx.
Backspaces one logical record on print file on
equipment defined by EST ordinal xx.
BKSPxx,rr.
Backspaces rr logical records on print file on
equipment defined by EST ordinal xx.
BKSPFxx.
Backspaces one file on print file on equipment
defined by EST ordinal xx.
BKSPFxx,ff.
Backspaces ff files on print file on equipment
defined by EST ordinal xx.
BKSPRUxx,ss.
Backspaces ss sectors on print file on equipment
defined by EST ordinal xx. Printing resumes at
the beginning of a line.
CONTINUExx.
Resumes printing on equipment defined by EST
ordinal xx.
ENDxx.
Terminates current operation on BA TCHIO
equipment defined by EST ordinal xx. If xx
defines a line printer or card punch, BATCHIO
will then assign the next available file to that
equipment. If xx defines a card reader that is
actively reading cards when ENDxx is entered, the
job terminates at the last card read. The next
card is treated as the beginning of a new job. If
another card deck follows the end-of-information
card (multipunch 6/7/8/9),' it is processed normally.
If xx defines a card reader that is stopped because
of a compare error when ENDxx is entered,
perform the following steps:
1.
Remove the remainder of the card
deck, except the end-of-information
card, from' the card reader input
hopper.
2. Ready the card reader to read the
end-of-information card.
The job terminates and if an'other card deck
follows the end-of-information card, it is
processed normally.
ENDxx,yy.
Terminates current operation on BA TCHIO
equipment defined by EST ordinal xx. The yy
parameter replaces any portion of the repeat
count specified for that equipment (refer to
REPEA T commands). For example, if the current
operation on equipment xx had been set to be
repeated five times (operation performed six
times), entering a value of 03 for yy would only
permit the operation to be performed three
times. If the repeat count is zero, this command
performs the same function as the preceding
command.
REPEA Txx.
tt
Repeats the current operation on BATCHIO
equipment defined by EST ordinal xx one time.
REPEATxx,yy.
tt
Repeats the current operation on BATCHIO
equipment defined by EST ordinal xx the number
of times specified by yy. The maximum value
that can be entered for yy is
77
octal.
-,\
I
t
These values are allowed but will default to 596-1.
I
/'
tt
When the current BATCHIO operation
is
repeated/rerun, maximum line and card limits are reinitialized prior to printing
or punching of the file being processed. User control limits apply
individuall~
to each output file copy produced.
60435600 K
3-17
