Enter the code that corresponds to the reason for the
scheduled event. The item you select appears on the line
labeled REASON.
I
NOTE
I
Exact information
is
required for
all
reason entries.
If you do not know the
reason for the event, enter the code for
UNKNOWN.
I
NOTE
I
For scheduled events the system does not
ask for
the component, lost time, or
impact entries.
The next display that
appears asks for the elapsed time.
This
entry
is
described
following
the
component descriptions.
COMPONENT ENTRIES
Figure 2-27 shows the resulting display when 1 was entered
in response to the initial display.
If the reason for an unscheduled event is OTHER, the
following display (figure 2-28) appears.
Select the most likely reason for the event. The item you
select appears on the line labeled REASON. Selecting 0, 1,
2, or 3 leads to a subsidiary list asking for the component
causing the failure.
Selecting 4 (UNKNOWN) causes a
branch to the elapsed time display.
Enter the code that caused the event. The item you select
appears on the line labeled COMPONENT.
60435600
J
CYBERLOG
EVENT TYPE:
UNSCHEDULED
ENTER THE CODE FOR REASON FOR EVENT
CODE
a
1
2
3
4
DESCRIPTION
OTHER
HARDWARE
SOFTWARE
COMMUNICATIONS
UNKNOWN
Figure 2-27. CYBERLOG Display for Unscheduled Event
CYBERLOG
EVENT TYPE:
UNSCHEDULED
REASON:
OTHER
ENTER THE CODE FOR THE COMPONENT CAUSING FAILURE
CODE
a
1
2
3
4
5
DESCRIPTION
OTHER
TEMP - HUMIDITY
ELECTRICAL
POWER SUPPLY
PROCEDURAL
UNKNOWN
Figure 2-28. CYBERLOG Display for Unscheduled Event Caused by Other
2-29
