ACTIVE JOB QUEUES (Q) DISPLAY
The
Q
display shows the status· of the active input, rollout,
and output queues. Three columns are displayed, one for
each queue. Each entry is in the following format.
no jobname queue priority fl/status
no
jobname
queue priority
fI/status
ecsfI
FNT ordinal of the job (same as
on H display).
System-assigned job name.
Priority assigned to the job
within the queue.
Job field length divided
by
100
r.eq~ired
to be assigned to
central memory, or one of the
following s~atus codes
associated with a rolled-out file:
MG Waiting for MAGNET.
PF Waiting for permanent
file.
RS Waiting for resources.
TE Timed/event rollout
file.
UA
Waiting for utility.
ECS field length divided by
1000.
If any column is too long for the screen, the message
MORE FILES.
appears at the end of that column.
Figure 4-20 illustrates the job queues display.
4-32
EXPORT/IMPORT STATUS (R) DISPLAY
The R display shows the current status of Export/Import
subsystem users Jogged in on 200 user terminals or 731-12
or
732-12
remote batch terminals.
A
header line contains
the total number of users since Export/Import was
initialized and the current number of active users. Each
entry appears in the following format.
line login user read print jobsin jobsout
line
login
user
read
Multiplexer line on which the user is
logged in (counting from one).
Time the user logged in.
User number of current user.
Reader status:
IDLE· (no data currently required
from reader).
NOT READY.
Name of job being read.
print Printer status:
SUSPENDED (transmission of a
print file has been suspended by
terminal operator or the printer is
not ready).
IDLE (no data currently being sent
to printer).
Name of the job being printed.
jobsin Number of jobs input since login.
jobsout Number of jobs output since login.
The user counts in the header line do not always agree with
those shown on the B display. The R display is an octal
count and counts the actual number of jobs logged in. The
B display is a decimal count and counts the actual number
of jobs reading or printing.
Figure
4-21
illustrates the Export/Import status display.
60435600 K
