2 Preparations
3. Recommended Wires, Ferrules and Crimp Tools
 Recommended Wires (stranded or solid wires)
Recommended wires
AWG24 to AWG16 (0.25 to 1.5 mm
 Recommended Ferrules
Applicable wire
2
(AWG)
(mm )
0.25 24
0.34 22
0.5 20
0.75 18
1 or 18 or
1.25 17
1.25 or 17 or
1.5 16
Recommended crimp tool
Note1: Make sure that the outer diameter of the wire coating is smaller than the inner diameter of the insulation
sleeve of the recommended ferrule.
2: Make sure that the ferrule processing dimensions conform to the following figures.
1.9 mm max.
2 - 60
Stripping length (ferrules not used)
2 8 mm
)
Ferrule Stripping
conductor length (mm)
length (ferrules
(mm) used)
8 10
10 12
8 10
10 12
8 10
10 12
8 10
10 12
8 10
10 12
8 10
10 12
8 to 10 mm
2.6 mm max.
Recommended ferrules
Manufactured by Manufactured by
Phoenix Contact Weidmuller
AI0,25-8 H0.25/12
AI0,25-10 ---
AI0,34-8 H0.34/12
AI0,34-10 ---
AI0,5-8 H0.5/14
AI0,5-10 H0.5/16
AI0,75-8 H0.75/14
AI0,75-10 H0.75/16
AI1-8 H1.0/14
AI1-10 H1.0/16
AI1,5-8 H1.5/14
AI1,5-10 H1.5/16
CRIMPFOX6
CRIMPFOX6T-F PZ6 roto
CRIMPFOX10S
E5@C Digital Temperature Controllers User's Manual (H174)
Manufactured by
Wago
FE-0.25-8N-YE
---
FE-0.34-8N-TQ
---
FE-0.5-8N-WH
FE-0.5-10N-WH
FE-0.75-8N-GY
FE-0.75-10N-GY
FE-1.0-8N-RD
FE-1.0-10N-RD
FE-1.5-8N-BK
FE-1.5-10N-BK
Variocrimp4
