6 Parameters
The following table shows the contents of the No. 1, 2, and 3 displays, according to the set-
ting of the PV/SP Display Screen Selection parameter.
Function
Set value
Setting
*1 The set value of the Alarm Value 1 parameter is displayed even if it is not valid due to the setting
of the Alarm 1 Type parameter.
Process value
For a temperature input, the decimal point position depends on the currently selected sen-
sor, and for an analog input it depends on the Decimal Point parameter setting.
PV/SP Display Selections
PV/SP No. 1 Display Selection
PV/SP No. 2 Display Selection
*
 Related Parameters
See
See
PV/SP Display Selection (Advanced Function Setting Level): Page 6-92
6 - 8
Process Value/Set Point 1
Process Value/Set Point 2
No. 1 display
0 Nothing is displayed.
1 Process value
2 Process value
3 Set point
4 Process value
5 Process value
6 Process value
7 Process value
8 Process value
Temperature input: The specified range for the specified sensor.
Analog input: Scaling lower limit −5% FS to Scaling upper limit +5%
FS
Set point SP lower limit to SP upper limit
Parameter
The default is 1 for models other than the E5@C-@-0@.
PV/SP No. 1 Display Selection must not be set to 0.
PV/SP No. 2 Display Selection must not be set to 0.
No. 3 display (E5EC, E5EC-B,
No. 2 display
Nothing is displayed. Nothing is displayed.
Set point Nothing is displayed.
Nothing is displayed. Nothing is displayed.
SP (character display) Nothing is displayed.
Set point MV (valve opening for
Position-proportional Models)
Set point Multi-SP No.
Set point
Soak time remain
Set point Internal set point (ramp SP)
Set point
Alarm value 1
Monitor range
Setting range
Default
4*
0
E5@C Digital Temperature Controllers User's Manual (H174)
and E5AC only)
000
*1
Unit
EU
Unit
EU
