6 Parameters
Setting
*1 PRST (Program Start) can be set even when the Program Pattern parameter is set to OFF, but
the function will be disabled.
*2 This function can be set only for a Digital Controller that supports a remote SP.
*3 This function can be set for heating/cooling control or for floating control for
Position-proportional Models, but the setting will be disabled.
*4 This function can be set only for a Digital Controller that supports communications. Also, if a
work bit is selected as the event input data, you cannot select communications writing
enable/disable.
*5 The following table shows the relationships between the ON/OFF status of multi-SP number
switching bits 0 to 2 and the set point.
Selected set point
Note: Any bits that are not assigned to event inputs are treated as being OFF.
 Related Parameter
See
See
SP 0 to 7 (Adjustment Level): Page 6-26
6 - 58
Setting
None
none
RUN/STOP
stop
Auto/Manual
manu
prst
Program Start
Invert Direct/Reverse Operation
drs
rsp
SP Mode Switch
100% AT Execute/Cancel
at-2
at-1
40% AT Execute/Cancel
Setting Change Enable/Disable
wtpt
cmwt
Communications Writing Enable/Disable
Alarm Latch Cancel
lat
msp0
Multi-SP No. Switching Bit 0
msp1
Multi-SP No. Switching Bit 1
msp2
Multi-SP No. Switching Bit 2
Bit 0
SP 0 OFF
SP 1 ON
SP 2 OFF
SP 3 ON
SP 4 OFF
SP 5 ON
SP 6 OFF
SP 7 ON
Function
*1
*2
*3
*4
*5
*5
*5
Multi-SP No. switching bits
Bit 1
OFF
OFF
ON
ON
OFF
OFF
ON
ON
E5@C Digital Temperature Controllers User's Manual (H174)
Bit 2
OFF
OFF
OFF
OFF
ON
ON
ON
ON
