General description

Description of the controller system (with all options)

NT Family controllers are comprehensive AMF-controllers for single and multiple generating sets operating
in stand-by or parallel modes. A modular construction allows upgrades to different levels of complexity in
order to provide the best solution for various customer applications.
NT Family controllers are equipped with a powerful graphic display showing icons, symbols and bar-graphs
for intuitive operation, which sets, together with high functionality, new standards in Gen-set controls.
The controller automatically starts the gen-set, closes the Gen-set C.B. when all conditions are met, then
stops the engine* (* sw GeCon opens GCB only, not stops the engine) on external signal or by pressing
push buttons.
Parallel to the Mains operation is a standard feature. Isolated parallel and Power Management System
support are optional. Forward and reverse synchronizing, Generator protections, Mains protection including
vector shift, load and power factor control are the major functions provided. Interfacing to foreign
synchronizers and load sharers is supported.
The key feature of the controller is its easy-to-use operation and installation. Predefined configurations for
typical applications are available as well as user-defined configurations for special applications.

Comparing of IGS-NT-GeCon-MARINE 3.2 with standard gen-set fw

GeCon does not take care of Engine control
GeCon accepts in SEM mode external control of GCB and Engine
GeCon can control the engine via Binary start/stop output signals only – see below. The independent Engine
controller (e.g. ID-DCU) is expected.
Synchronizing and unloading timeouts can be disabled by setpoint setting (or Force value function)
All regulations (load, VAr sharing, frequency, voltage) can be disabled by setpoint change or by Force value.
Interface GeCon to engine controller is provided by I/O wires no by communication line.

Available documentation

PDF
FILE
IGS-NT & ID-DCU Accessory Modules 02-
2015.pdf
IGS-NT Troubleshooting Guide 08-2014.pdf
IGS-NT Communication Guide 09-2014.pdf
IGS-NT Installation Guide 08-2014.pdf
IGS-NT Application Guide 05-2013.pdf
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
D
ESCRIPTION
Thorough description of accessory modules for IGS-NT
family, technical data, information about installation of the
modules, how to connect them to controller and set them
properly.
How to solve most common troubles with InteliGen NT and
InteliSys NT controllers. Including the list of alarm massages.
Communication guide for IG/IS-NT controllers. It contains
information how to connect control unit and all
communication features descriptions
Installation guide for IG/IS-NT controllers. It contains
technical information about controler and extension modules
Application guide for IG/IS-NT controllers. It refers to
application and typical installation settings and sites
structures
7
