ComAp IG-NT GC Reference Manual page 192

N
OTE
The AVR is recommended to be configured for droop function when these outputs
are used for power factor control.
N
OTE
The alarm Wrn VoltRegLim is disabled when this output is used (configured onto
any controller terminal or virtual output).
Binary output: Vgen <>
Related FW 3.2
Description The output is closed while the generator over/under voltage alarm is present in the
alarm list.
Binary output: Vmains <>
Related FW 3.2
Description The output is closed while the mains over/under voltage alarm is present in the
alarm list.
Binary output: VectorShiftTrp
Related FW 3.2
Description The output closes if the Vector shift protection gets active and the controller trips
the selected breaker. The output stays closed for 3s, then opens again.
N
OTE
See also the output VectorShiftAct.
Binary output: VectorShiftAct
Related FW 3.2
Description The output closes if the Vector shift protection gets active. It stays closed for 3s,
then opens again. This output is activated even if the selected breaker is actually
not tripped because of the input
N
OTE
See also the output VectorShiftTrp.
Binary output: PeriphCommErr
Related FW 3.2
Description The output is closed while there is an error in the communication with any
peripheral unit (e.g. IS-AIN8, IGS-PTM, ...).
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
:
:
:
:
Sd override is active.
