ComAp IG-NT GC Reference Manual page 127

Related FW 3.2
Description This is a bit array containing status of logical binary outputs 49-64 of the
controller. Bit0 represents LBO49, bit1 represents LBO50 etc..
N
OTE
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
N
OTE
Click on button with "..." to get a clear list of BI names with their corresponding
values.
Value: LogBout 5
Group Log bout
Units -
Related FW 3.2
Description This is a bit array containing status of logical binary outputs 65-80 of the
controller. Bit0 represents LBO65, bit1 represents LBO66 etc..
N
OTE
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
N
OTE
Click on button with "..." to get a clear list of BI names with their corresponding
values.
Value: LogBout 6
Group Log bout
Units -
Related FW 3.2
Description This is a bit array containing status of logical binary outputs 81-96 of the
controller. Bit0 represents LBO81, bit1 represents LBO82 etc..
N
OTE
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
N
OTE
Click on button with "..." to get a clear list of BI names with their corresponding
values.
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
:
:
:
:
:
:
127
