ComAp IG-NT GC Reference Manual page 163

Binary input: ForceValueIn14
Related FW 3.2
Description This input activates the Force value #14 block. If the input is active, the value of
the setpoint, to which the Force value #14 block is configured, will be overriden by
value of the alternative setpoint assigned to the Force value #14 block.
N
OTE
If there are more than one force value blocks configured onto one setpoint then
the highest priority has the block with the lowest index (i.e. the first active block
according to the list displayed in GenConfig in the Force value window at the
related setpoint).
N
OTE
Watch a training video about force value function here:
http://www.comap.cz/support/training/training-videos/.
N
OTE
See an example in the description of the binary input
Binary input: ForceValueIn15
Related FW 3.2
This input activates the Force value #15 block. If the input is active, the value of
Description
the setpoint, to which the Force value #15 block is configured, will be overriden by
value of the alternative setpoint assigned to the Force value #15 block.
N
OTE
If there are more than one force value blocks configured onto one setpoint then
the highest priority has the block with the lowest index (i.e. the first active block
according to the list displayed in GenConfig in the Force value window at the
related setpoint).
N
OTE
Watch a training video about force value function here:
http://www.comap.cz/support/training/training-videos/.
N
OTE
See an example in the description of the binary input
Binary input: ForceValueIn16
Related FW 3.2
Description This input activates the Force value #16 block. If the input is active, the value of
the setpoint, to which the Force value #16 block is configured, will be overriden by
value of the alternative setpoint assigned to the Force value #16 block.
N
OTE
If there are more than one force value blocks configured onto one setpoint then
the highest priority has the block with the lowest index (i.e. the first active block
according to the list displayed in GenConfig in the Force value window at the
related setpoint).
N
OTE
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
:
:
:
:
:
:
:
:
Force value 1.
Force value 1.
163
