Setpoints

Password protection
Any setpoint can be password protected - 7 levels of password is available. The password is a four-digit
number. Only setpoints associated with the entered password level can be modified.
Even though one level may have been set from the front panel, the affected setpoints are not accessible
from InteliMonitor (direct or Modem) until this level is set in IMON (InteliMONitor). Setpoints opened from
front panel are automatically closed 15 minutes after the last key has been pressed or when wrong value of
password is set. Any password can be changed once that level password or higher has been entered.
The controller programming (configuration) requires the highest password - 7 level.

ProcessControl

BaseLoad
This setpoint is used for adjusting of the requested gen-set power in Baseload mode, i.e. if the setpoint
ctrl PtM is set to BASELOAD
Step: 0,1 kW / 1 kW / 0,01 MW*
0,1 kW – 650,00 MW*
Range:
ForceValue possibility: No
*Note:
The actual setpoint units and range depend on setting of the Power format (see GenConfig manual).
Hint:
If you set this setpoint to a higher value than the system is available to produce, the total produced power is
limited with the sum of Nomin power setpoints of all gen-sets in the system.
Base PF
This setpoint is used for adjusting of the requested gen-set power factor value if the power factor control
mode is set to BASEPF (setpoint
Values over 1.00 mean capacitive load character, i.e. setting 0.95 means 0.95L and setting 1.05 means
0.95C.
Step: 0,01
Range: 0,60 - 1,20
Import load
This setpoint is used for adjusting of the requested mains import if the gen-set load control mode is set to
IMP/EXP (Load ctrl PtM
This setpoint is also used for adjusting of the maximum allowed export if export limit function is active
limit = ENABLED).
Range: -32000 .. 32000 [kW]
N :
OTE
Negative value of import is export, i.e. the power flows into the mains.
N :
OTE
The actual setpoint units and range depend on setting of the Power format in GenConfig.
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
[ kW – MW*]
[ ]
PF ctrl PtM).
[ kW ]
= IMP/EXP)
Load
(Export
60
