ComAp IG-NT GC Reference Manual page 114

Related FW 3.2
Description Generator current in phase L3.
N
OTE
The ratio between the current measured at the input terminals and the displayed
current is adjusted by the setpoints
Value: Gen V unbal
Group Gener values
Units %
Related FW 3.2
Description Generator voltage unbalance. The value is calculated as maximal difference of
two phase voltages at one moment and expressed in % of the nominal voltage.
N
OTE
This value can be used for creating the generator voltage unbalance protection
using the "universal analog protections".
Value: Gen I unbal
Group Gener values
Units V
Related FW 3.2
Description Generator current unbalance. The value is calculated as maximal difference of
two phase currents at one moment and expressed in % of the nominal current.
N
OTE
This value can be used for creating the generator current unbalance protection
using the "universal analog protections".
Value: Slip freq
Group Gener values
Units Hz
Related FW 3.2
Description Differential frequency between the generator and the mains/bus.
Value: Angle
Group Gener values
°
Units
Related FW 3.2
Description The angle between the phasors of the generator and mains/bus voltage.
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
:
:
:
CT ratio prim and CT ratio sec.
114
