Description If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
internal temperature of the module.
This analog input is intended for measuement of this thermocouple compensation
temperature for the IS-AIN8 module with index #1.
N
OTE
Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
Analog input: Cold temp 2
Related FW 3.2
Description If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
internal temperature of the module.
This analog input is intended for measuement of this thermocouple compensation
temperature for the IS-AIN8 module with index #2.
N
OTE
Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
Analog input: Cold temp 3
Related FW 3.2
Description If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
internal temperature of the module.
This analog input is intended for measuement of this thermocouple compensation
temperature for the IS-AIN8 module with index #3.
N
OTE
Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
Analog input: Cold temp 4
Related FW 3.2
Description If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
