BinInp delay 2
Binary input protection is activated when input is closed for longer time than BinInp delay 2. To use this delay
Binary input must be configured in GenConfig for Property – Delay = BinInp delay 2.
Step: 0,1s
0,0 – 600,0 s
Range:
Force value: Yes
BinInp delay 3
Binary input protection is activated when input is closed for longer time than BinInp delay 3. To use this delay
Binary input must be configured in GenConfig for Property – Delay = BinInp delay 3.
Step: 0,1s
0,0 – 600,0 s
Range:
Force value: Yes
Hint:
BinInp delay is active only for Binary inputs configured as protection.
If these setpoints are not used, default BI delay is 0,5s.
ForceBlockDel1
ForceBlockDel2
ForceBlockDel3
ForceBlockDel4
ForceBlockDel5
ForceBlockDel6
Delays for Force block protection activation after the corresponding Binary input Force block is opened.
Protection deactivation is without delay. Protection is activated/deactivated independent on engine running
or not running state – it depends only on the corresponding Force block X input.
Step: 0,1s
0,0 – 60,0 s
Range:
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
[ s ] (FV)
[ s ] (FV)
DriveConfig: I/O, Property, Protection active = Closed
BINARY INPUT
physical
BINARY INPUT
Internal value
closed
BINARY INPUT
physical
BINARY INPUT
Internal value
DriveConfig: I/O, Property, Protection active = Opened
BINARY INPUT
opened
physical
BINARY INPUT
Internal value
[ s ] (FV)
[ s ] (FV)
[ s ] (FV)
[ s ] (FV)
[ s ] (FV)
[ s ] (FV)
BinInp delay
no change
BinInp delay
BinInp delay
