Binary output: Stopping
Related FW 3.2
Description The output closes when the Stop pulse was sent to engine controller and
LBI:RadyToLoad is still active
Binary output: Stopped
Related FW 3.2
Description The output closes when the Stop pulse was sent to engine controller and
LBI:RadyToLoad is not active
Binary output: Logical 0
Related FW 3.2
Description This output is always opened. It may be used in functions (e.g. ECU outputs or
PLC modules inputs) where a binary value is required, however it has to be
continously inactive.
Binary output: Logical 1
Related FW 3.2
Description This output is always closed. It may be used in functions (e.g. ECU outputs or
PLC modules inputs) where continuously active binary value is required.
Binary output: Remote S/S
Related FW 3.2
Description This output is active
Binary output: WrongPhSeq
Related FW 3.2
Description Binary output WrongPhSeq is active when at least one of the following conditions
is fulfilled: Generator/Mains/Bus phase is inverted or wrong generator/mains/bus
phase sequence or opposed generator/mains/bus phase sequence is detected.
Binary output: User Button 1
Related FW 3.2
Description This output can be specified for example on buttons on IV-5/8 or in SCADA
diagram in InteliMonitor. Its state depends on function assigned to the related
