Timer settings

TimerChannel1 ... TimerChannel16
Defines the setting of particular timer channel.
There is 16 channels, each defines occurrence date and time (year, month, day, hour, minute), duration time
(in minutes, maximum is 24*60), repeating period (day, week, month, once). In case of week – day of the
week selection, when should be executed + selection of repeating (every 1 , 2 , 3 or 4 week); In case of
st nd rd th
month – day of the month selection (e.g. every 3
day or every 2 Monday)
rd nd
Every channel can be disabled by blocking input (physical input or logical output). If blocking input is active
then the timer is not activated.
All the channels are divided into groups of 4. Every group can have independent binary input. There is also
one common input for all 16 channels.
