Gen-set operation states

Gen-set can operate in following states
Not ready Gen-set is not ready to start
Fw and archive incompatibility or invalid values in setpoint – controller does not work
Init
Starting Waiting for ReadyToLoad signal
Running Waiting for GCB connection or start synchronizing
Soft load Gen-set power is ramping up
Loaded Gen-set is loaded
Soft unld Gen-set power is ramping down
Stopping Stopping procedure before the BI ReadyToLoad is opened.
Stopped - initial state – waiting for engine start. LBI:ReadytoLoad is deactived.
Stopped
Breakers conditions
MainsOper Mains is present (MCB is closed, GCB is opened)
IslOper Island operation (MCB is opened, GCB is closed)
Brks Off GCB, MCB opened
Synchro Gen-set is synchronizing (MCB is closed, GCB is
opened)
ParalOper Gen-set is in parallel with mains (MCB is closed,
GCB is closed)
