ComAp IG-NT GC Reference Manual page 204

Description This output is closed at the end of the
closed to switch the gen-set to nominal speed. The output is opened when the
gen-set goes to cooling phase or performs a shutdown.
Binary output: ForwardSynchro
Related FW 3.2
Description The output is closed during forward synchronizing and opens when the output
GCB status
N
OTE
The output can be used for control of an external synchronizing module.
Binary output: ReverseSynchro
Related FW 3.2
Description The output is closed during reverse synchronizing (synchronizing of loaded gen-
set back to the mains) and opens when the output
MCB was closed).
N
OTE
The output can be used for external synchronizing module control.
Binary output: Soft load
Related FW 3.2
The output is closed during gen-set soft loading period – i.e. it is closed when the
Description
gen-set has been synchronized to the mains/bus and GCB has been closed and
opened again when the ramp of the gen-set power reached the required level.
N
OTE
The output is not closed during the warming period.
Binary output: Loaded
Related FW 3.2
Description The output is closed while the gen-set is loaded and the load is beeing regulated
according to selected mode (baseload, import/export, power management etc.) or
is not beeing regulated in single island operation.
Binary output: Soft unld
Related FW 3.2
Description The output is closed while the gen-set is beeing unloaded before opening GCB.
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
is activated (= GCB was closed).
:
:
:
Idle phase when the output
MCB status
Idle/Nominal is
is activated (=
204
