RS232(1)MBCSpd
Defines the communication speed on RS232(1) line when ModBus mode is selected.
RS232(2)MBCSpd
Defines the communication speed on RS232(2) line when ModBus mode is selected. Available only in IS-NT
and in IG-xxC versions.
RS232(1)MdmIni
Auxiliary modem initialization string – executed after the default modem initialization string. Used with
modem connected to the RS232(1) communication port.
Hint:
Applicable only for MODEM(HW), MODEM(SW) and MODBUS-MDM(HW) modes.
Use for special AT command setting of your modem if default string does not initiate the modem properly. AT
commands must be separated using semicolon ";", max. length 31 characters.
The setpoint can be changed only using PC SW when configuring IG-EE/NT.
RS232(2)MdmIni
Auxiliary modem initialization string – executed after the default modem initialization string. Used with
modem connected to the RS232(2) communication port.
Available only in IS-NT and in IG-xxC versions.
Hint:
Applicable only for MODEM(HW), MODEM(SW) and MODBUS-MDM(HW) modes.
Use for special AT command setting of your modem if default string does not initiate the modem properly. AT
commands must be separated using semicolon ";", max. length 31 characters.
The setpoint can be changed only using PC SW when configuring IG-EE/NT.
RS485(1) conv.
If set to ENABLED, the communication RS232(1) port is redirected to the built-in RS485 converter. That
means the remote display RS485 line (for IG-Disp connection) is blocked and the converter is used for
communication with superior system or ECU.
Available in all controllers except of IS-NT.
Hint:
Applicable only for DIRECT, MODBUS-DIRECT modes.
This converter is not isolated!
RS485(2) conv.
If set to ENABLED, the communication RS232(2) port is redirected to the built-in isolated RS485 converter.
Available only in IS-NT and in IG-xxC versions.
Hint:
Applicable only for DIRECT, MODBUS-DIRECT modes.
CAN bus mode
CAN bus speed selection.
32C: High speed CAN (250 kbps) applicable up to 32 controllers, CAN bus length limited up to 200
meters.
8C: Low speed CAN (50 kbps) applicable up to 8 controllers, CAN bus length limited up to 900 meters.
Hint:
Low speed use for long distance connection only. Set all connected controllers to the same speed.
If having problems with needed CAN bus length, see Communication guide / I-CR module.
CAN2emptDetect
Enables the detection of missing intercontroller CAN connection. If enabled and no other controllers are
detected on the CAN bus (the complete bus, not only within the logical group), this protection activates.
Force value: Yes
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
[ 9600 bps / 19200 bps / 38400 bps / 57600 bps ]
[ 9600 bps / 19200 bps / 38400 bps / 57600 bps ]
[ ]
[ ]
[ DISABLED / ENABLED ]
[ DISABLED / ENABLED ]
[ 32C / 8C ]
[ DISABLED / ENABLED ] (FV)
