User Mask Function - ComAp IG-NT GC Reference Manual

Selects which button is this function mapped to
(0 – first button, 1 – second button and so on)
Adjust text for the button
when it is active or inactive
Choose UserButton index and
its function (ON/OFF etc.)
Choose which colour will be
Select which condition triggers
available for this button
which coulour
Available functions for soft buttons are listed in the following table.
ON Pressing the button changes the state of log. Binary Output U
When the output is closed and the button is pressed state is not changed.
OFF Pressing the button changes the state of log. Binary Output U
When the output is opened and the button is pressed state is not changed.
ON/OFF Pressing the button changes the state of log. Binary Output U
closed depending on previous state (it is changed to the opposite state).
P ON Pressing the button issues log. Binary Output U
ULSE
N :
OTE
Repeated pressing of button during the closed period (one second) causes issuing other
puls of length of one second to be generated from the moment of button pushing.
H
INT
It is possible to lock User Button with password (go to tab Commands in GenConfig). User Buttons 1-5, 6-8
and 9-16 can be locked separately. It is also possible to use User Buttons in SCADA diagrams.

User Mask function

In GenConfig you can easily set any object in Screen Editor to show or hide based on activation of particular
Logical Binary Input available for users. Below, there is diagram showing the setup of User Mask function in
Screen Editor.
