Summary of Contents for ComAp IG-NT GC

Page 1 Compact Controller for Stand-by and Parallel Operating Gen-sets Inteli New Technology Modular Generator Controller Multiple Internal engines application – SW configuration MINT IG-NT GC, IG-NTC GC, IS-NT,IG-NT-BB, IG-NTC-BB, IS-NTC-BB Software version IGS-NT-GeCon-MARINE-3.2, July 2015 REFERENCE GUIDE Copyright © 2015 ComAp a.s. ComAp a.s..
Page 2: Table Of Contents
Basic settings ............................... 57 Delays/Timers .............................. 68 Analog protect .............................. 71 Gener protect ............................... 72 Pwr management ............................79 HeavyConsumers ............................84 Sync/Load ctrl............................... 84 Sync/load control adjustment ........................84 Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 3: Table Of Contents
Direct connection to the PC ........................221 GenConfig functions ........................... 221 InteliMonitor ..............................222 Modbus protocol ............................222 Value and setpoint codes ........................... 222 Technical data ............................222 Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 4: General Guidelines
Note: ComAp believes that all information provided herein is correct and reliable and reserves the right to update at any time. ComAp does not assume any responsibility for its use unless otherwise expressly undertaken.
Page 5: Dangerous Voltage
This type of paragraph indicates things, procedures, adjustments, etc. which demand a high level of attention, otherwise personal injury or death may occur. XAMPLE This type of paragraph indicates examples of usage for illustrational purposes. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 6: Available Firmware And Archive Sets
Some features are available only in InteliGen NT Basebox, InteliGen NTC Basebox and InteliSys NT. These features are highlighted by green background. Features which are not available in InteliGen GC controller: User MODBUS Distributed Binary Inputs and Outputs Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 7: General Description
Installation guide for IG/IS-NT controllers. It contains technical information about controler and extension modules Application guide for IG/IS-NT controllers. It refers to IGS-NT Application Guide 05-2013.pdf application and typical installation settings and sites structures Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 8 IGS-NT Operator Guide 01-2014.pdf Operator guide for IG/IS-NT Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 9: Example Of Interconnection Gecon X Engine Controller
From GeCon side: BO: Start pulse, Stop pulse - for sending Start and Stop signals Speed control (during synchronisation, regulation): BO: Speed Up, Speed Down or Aout SG out Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 10 In case of connection IB-NT or I-LB+ - you can monitor both kind of units (IGS-NT, ID-DCU) In case of connection display – you can switch between both kind of units (IGS-NT, ID-DCU) Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 11: Functions
GCB open level NO LEVEL 1-100% 1-100% GCB open del NO TIMEOUT 1-1800s 1-1800s Hint: It is possible to configure (Force value) “HAND” – SEM switching via Binary input. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 12: Controller Modes
Gen-set cannot be started and operated from IGS-NT-GeCon controller – no response for panel buttons and Binary input commands. Hint: Switching to OFF mode is blocked on running engine to avoid accidental engine stop by mode change or by firmware or configuration programming. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 13 ProtectionMode = NOT ACTIVE Sync/Load ctrl: Sync timeout = NO TIMEOUT External Engine GCB open level = NO LEVEL Start / Stop GCB open del = NO TIMEOUT Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 14 Remotely e.g. from InteliMonitor LBI: Gen unload GCB closing from controller can be blocked by BI: GCB disable (does not block synchronization process) Controller flow chart in SEM mode: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 15 GeCon BI: Sys start/stop GeCon will stop engine started from engine controller when BI Sys start/stop or due to Power management function. Controller flow chart in AUT mode: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 16: Power Management
Guarantees that the engines will be not continuously loaded more than to a certain level, leaving less than selected relative load reserve. Suitable for engine life-based optimization. Activation: #Pwr mgmt mode = REL (%) Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 17 Sum of Actual power of all gen-sets on the bus = system load. Hint: Optional functions in absolute or relative Power management are: Running hours balancing (equalization), Load demand (different size) engines swap and Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 18 Three running engines (priorities) are swapped based on load demand (one “small” engine runs on “small” load and swaps to another one “big” engine that runs when load increases). Activation: #PriorAutoSwap = LD DEMAND SWAP Important setpoints: #PwrBandContr1, #PwrBandContr2, #PwrBandContr3, #PwrBandContr4, #PwrBandChngDe. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 19 GroupLinkLeft = C GroupLinkLeft = 1 GroupLinkRight = C GroupLinkRight = C GroupLinkRight = C GroupLinkRight = C GroupLinkRight = 2 Control group 1. Control group 2. BTB feedback Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 20: Deadbusstart Function
LdShed stage 1 Load shedding: LdShed stage 2 ManualLdRecon CurShedLev CurRecLev Ld Shed delay FreqShedLvl Ld recon delay FreqRecLvl LdShed stage 10 Hint: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 21 BO Load shed 2 opened BO Load shed 1 opened Ld recon del Ld recon del Ld recon del Load reconnection – manual -> AutoLd recon = DISABLED Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 22: Droop
This setpoint defines the value of requested power on the requested frequency (Basic settings: Nominal freq + Nom frq offset). Allows to shift the droop correlation line up or down. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 23 Droop mode allows cooperation of gen-set equipped by ComAp control system with gen-set equipped by any third party control system. The steady bus voltage and bus frequency has to be regulated by this third party control system. Active and reactive power of gen-set equipped by ComAp controller is kept on values given by droop settings.
Page 24: Protection Mode Settings
If the Mains voltage is > 15V and MCBfdb=1 and GCBfdb=1 and LBI:ReadyToLoad=0 then BO GCB Fail and History record are performed. SPI application: Mode: SEM External GCB control is accepted only when LBI:ReadyToLoad=1. Exceptions: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 25: Heavy Consumers Support
Each controller counts level for start and stop (in power management system) locally, so user must ensure correct activation of Heavy consumer inputs in all controllers (for example via Share Inputs/Outputs). Solution is shown on the picture: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 26: Variable Speed Support
By changing speed on genset is possible to achieve lower fuel consumption. Frequency (and Voltage) are usually control according to current load. For variable speed is used: Setpoints: Nominal freq 30..65 Hz (step 1 Hz) FV (Basic settings Group) Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 27: Force Value – Step By Step Guide
Force value – step by step guide In this chapter there is complete step by step guide which shows how to use Force value function of the controller. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 28 Integer 16 to a setpoint with dimension hours and which is as well Integer 16). You may use PLC block Convert to change the dimension and range if needed. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 29: Values For Continuous Writing From External Sources
Communication guide for InteliGen and InteliSys. User Buttons There are several User Buttons available in the controller. It is possible to set them on Soft Buttons in InteliVision 5 or 8. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 30: User Mask Function
In GenConfig you can easily set any object in Screen Editor to show or hide based on activation of particular Logical Binary Input available for users. Below, there is diagram showing the setup of User Mask function in Screen Editor. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 31: Remote Control Function
Remote Switch will activate or deactivate depending on remote control so it can be used to manually control devices, simulate malfunctions while commissioning etc. Figure: Remote Switches tool in InteliMonitor, Remote Switches tools in Line Diagram Editor and Mobus commands Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 32: Virtual Peripheral Inputs-Outputs (Vpio) Module
Shared Inputs and Outputs It is possible to share Binary and Analog values between all the controllers via CAN bus, thus saving physical Inputs and Outputs and excess wiring. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 33 Controller sends Shared Binary Outputs each 100ms if there are any changes in any bit position. If there are no changes, controller sends the information with period 1s. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 34: Distributed Binary Inputs And Outputs
1s. DISTBIN and DISTBOUT function is not available for IM-NT-GC and IG-NT(C)-GC controller. DISTBIN and DISTBOUT function is conditioned by IGS-NT-LSM+PMS dongle. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 35: Modbus Reading And Writing
Value, Setpoint, Alarm state Communication object number Standard Modbus register number User Modbus register number Select type Select object User MODBUS function is not available for IM-NT-GC controller. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 36: Modbus Switches
Last two Power Formats can be used in combination on one CAN bus. PLC functions Following functions are available in IGS-NT-GeCon-MARINE firmware. IS-NT-GeCon IG-NT-GeCon Group PLC Block MARINE MARINE Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 37: Multi Language Support
AVRi outputs can be connected as symmetrical: OUT1-OUT2 or unsymmetrical OUT1-OCOM or OUT2- OCOM.  Potentiometer on the AVRi defines maximal OUT1, OUT2 voltage range.  Use symmetrical (OUT1,OUT2) AVRi output to connect the AVRi to AVR auxiliary voltage input. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 38 When running in parallel 30% loaded increase slowly PF gain to unstable point and then decrease value by 30 % to insure stable performance. Adjust PF int (usually setting to 100% gives optimal performance). Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 39: Sync/Load Control Adjustment
Set Angle gain. Synchroscope on the controller measure screen should move slowly and stop in “up“ position. Set Angle gain to unstable value (synchroscope swings) and decrease value by 30 % to insure stable performance. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 40: Protections And Alarm Management
Can be indicated when Analog input value Alarmlist and History is ±6% out of sensor characteristic range. Fls can optionally activate corresponding (e.g. Sd) Analog input protection as well. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 41 Binary and analog protections configured as Sd override type. In fact this protection type means: "Unoverridable shutdown", i.e. it works the same way as standard shutdown protection, however it can not be overriden (blocked) by the Sd override input. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 42 BI: CB fdb BI: CB fdb neg When closing the CB, the CB status LBO switches over only when both feedbacks are in correct position BO: CB status Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 43 CB fail – If any inconsistence between the two feedback signals is detected, CB fail is issued. BI: CB fdb neg = 1 BO: CB status = 0 BO: CB fail Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 44 BO: CB ON coil BO: CB UV coil CB opening by protection or manual command (button pressed) BO: CB OFF coil BI: CB fdb BI: CB fdb neg BO: CB status Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 45 2 sec when the CB is used for synchronizing  5 sec in other cases BO GCB close/open opened BI GCB feedback opened Time delay active 5 sec Alarm: GCB fail Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 46  In case that CB fail is detected after switching the controller on (CB is closed), the CB OFF coil output is activated immediately. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 47: Gen-Set Operation States
Multiple Island - gen-set is running loaded in island parallel mode (MCB is open, GCB is closed) Multiple Parallel – gen-set is running loaded in MultParOp mains parallel mode (MCB is closed, GCB is closed) Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 48: Synchroscope Mode
Marine certification (e.q. Germanischer Lloyd certification) Correct connection for double check during synchronisation IGS-NT SynchroScope application GCB1 IGS-NT BO: In synchonism Gen-set Generator controller SynchScope configuration you can find in IGS-NT-GeCon-Marine package. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 49: Inputs And Outputs
For more details about Virtual peripherals (Shared and Internal virtual I/O periphery and PLC) see last version of IGS-NT-Application guide-x.x.pdf. AUTION Usage of any 3rd-party peripheral modules in cooperation with ComAp controller is not recommended. ComAp can’t guarantee the proper function of controller with none-ComAp peripheral modules. Analog outputs IS-NT controller has one analogue output, free configurable.
Page 50 This setting ensures that 0 kW (Low kW) will correspond to 4 mA. No analog output is available on IG-NT controller. Use extension unit IGS-PTM (one analog output) or I- AOUT8 (eight analog outputs). Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 51: Setpoints
5% of its nominal power then the gen-sets of the second and first highest address get to load sharing mode together (see the picture below). Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 52 You should set only one controller in the logical control group to send the data to the CAN bus (= AOUT virtual periphery source), otherwise the system will not work properly. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 53 (PMS: AnExSysBld) (PMS: AnExSysBld) EXTERNAL EXTERNAL Reg kW/kVAr [STD / DROOP / EMERG DROOP] (FV) STD: Standard isochronous Load Sharing and VAr Sharing are based on CAN intercontroller communication. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 54 (e.g. in default configuration). When Power derating function is active, the generator nominal power is decreased to DeratedX power and so Overload protection (BO Overload) is based on this Derated power! Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 55 Binary output Neutral CB C/O (Neutral contactor) is opened when gen-sets are running in parallel to the mains (MCB is closed). Following see a connection example for setting Neutral cont. = EACH Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 56 ProtectionMode [ ACTIVE / NOT ACTIVE ] (FV) ACTIVE: Standard setting – all protections are active. 2-nd level protections are evaluated, GCB or MCB is controlled. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 57: Basic Settings
[ /5A / /1A ] Gen-set phases Current Transformers ratio – secondary side selection /5A or /1A. Available in IG-xxC and IS-NT versions. In standard IG-EE/NT units only 5 A range available. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 58 E.g. if GenNomV is changed to 220 V, the GenNomVph-ph is changed to 220*1,73 = 381 V. BusNomV [ V ] (FV) Nominal bus voltage (phase to neutral). Step: 80 – 30000 V Range: Force value: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 59 Number of teeth on the engine’s flywheel for the pick-up sensor. This setpoint was added based on the customer's request to display RPM. GeCon just shows RPM value, but this value is NOT used for control of system. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 60 This setpoint adjusts timeout after which the display (internal display or IS display #1) backlight is switched off. When IntelliVision is used this setpoint does not adjust its behavior. Its backlight is adjusted by internal IntelliVision "setpoint". The backlight is off all the time Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 61 ENABLED - controller backlight is switch off during start of the engine. As soon as the engine proceed into Idle or Running state, the controller backlight is switched to original value. DISABLED - controller backlight is not damped during start procedure. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 62 Gen-set setting in PC SW. RS232(1) mode [ DIRECT / MODEM (HW) / MODEM (SW) / MODBUS-DIRECT / MODBUS-MDM(HW) / ECU link] Communication protocol selection for RS232(1) line. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 63 RS485 line (for IG-Disp connection) is blocked and the converter is used for communication with superior system or ECU. Available in all controllers except of IS-NT. Hint: Applicable only for DIRECT, MODBUS-DIRECT modes. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 64 DHCP server. It is not possible to change the setpoint value manually in this setting (the value is immediately reverted back by controller communication module IB-COM). IP Addr mode The setpoint is used to select the method how the ethernet connection is adjusted. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 65 1 .. 255 [-] This setpoint is used to adjust the port, which is used for ethernet connection to a PC with any of ComAp PC program (i.e. InteliMonitor, GenConfig). This setpoint should be adjusted to 23, which is the default port used by all ComAp PC programs.
Page 66 Range max. 32 characters [-] This setpoint is used for entering the domain name or IP address of the AirGate server. Use the free AirGate server provided by ComAp at address airgate.comap.cz if your company does not operate it's own AirGate server.
Page 67 Range [units] DISABLED, ENABLED [-] This setpoint is used to disable reading of diagnostic codes from the ECU if an external diagnostic tool is connected to the engine. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 68: Delays/Timers
Delay for Engine running Alarms activation – group 3. Step: 0,1s 0,0 – 3000,0 s Range: Force value: closed BINARY INPUT physical BinInp delayX PROTECTION BLOCKED RunOnlyBlkDelX Engine running state inactive active PROTECTION Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 69 DriveConfig: I/O, Property, Protection active = Closed BINARY INPUT physical BinInp delay BINARY INPUT no change Internal value closed BINARY INPUT physical BinInp delay BINARY INPUT Internal value Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 70 You can rename the particular timers using Translator to indicate specific service intervals – e.g. “OilChange time”, “SparkPlug time”, ... Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 71: Analog Protect
Minimum gen-set Power for Cylinder temperature Difference evaluation. The protection is not evaluated, if the gen-set power is lower than this limit. Step: 0,1 kW / 1 kW / 0,01 MW* Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 72: Gener Protect
When the IDMT protection is activated the GCB is opened, the event is recorded in the Alarmlist and History, and the engine will cool down and stop. 2POvrldStEvDel * OverldStrtEval Reaction time = Pgen - OverldStrtEval Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 73 6,875 3,056 No action 550 13,75 6,112 10,0 No action 1100 27,5 12,223 20,0 No action 2200 1100 24,445 50,0 No action No action 2750 1100 137,5 61,112 Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 74 Ishort del can be set to 0,01 s but this value is rounded to the proximate controller evaluation period. 2Inom del [ s ] IDMT curve shape selection. 2Inom del is the Reaction time of IDMT protection for 200% overcurrent Igen = 2* Nominal current. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 75 15 Amps from CT is measured and displayed as 11 Amps.  Take special care when selecting CT’s. All available 5 Amp CT’s do not have a range up to 11 Amps. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 76 [ % ] (FV) Threshold for generator under frequency in % of nominal frequency. Step: 0,1 % (0=OFF) 50,0 – Gen>f % of Nominal freq Range: Protection: BreakerOpen Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 77 ReversePwr del Range 0 .. 600.0 [s] The setpoint adjusts the delay for generator reverse power protection. The threshold for the protection is adjusted by setpoint Reverse power. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 78 (e.g. this setpoint is adjusted to 50% and nominal power of gen-set is 200 kW, therefore excitation loss protection level is set to -100 kVAr) Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 79: Pwr Management
For different sized engines, this mode allows to optimally select the running engines according to the actual site load. Up to 3 engines can cooperate in this mode. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 80 #LoadResStop 1 (2, 3, 4) level is achieved, the gen-set with the lowest priority (highest setpoint Priority) is stopped. Next gen-set is stopped when: > P + Reserve BNom Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 81 Yet another conditions must be fulfilled in this case. !!! IMPORTANT !!! Reserve for stop always has to be higher than corresponding reserve for start for all Power Management modes ! Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 82 Running hours base to correct actual Running hours (previous) differences between particular gen-sets. Step: Range: 0 - 200000 h Force value: Yes Example: Gen-set 1 actual Running hours = 1000 h. Gen-set 2 actual Running hours = 2000 h. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 83 Load Sharing and VAr Sharing independently on other groups, allowing more such groups to be present on the CAN bus. Groups can be linked together using GroupLink tools. Step: COMMON (=1), 2 – 32 Range: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 84: Heavyconsumers
, SpeedGovHiLim ~ 105% RPM nom. IMPORTANT Speed governor has to be adjusted for optimum performance before Sync / load control adjusting. Check generator phase sequence before the first GCB connection. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 85 See Voltage phases match indication on the controller Synchronizing screen. Example 1. Voltage match 1 2 3 Note: 1 1 0 Phase L3 is out of voltage window Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 86 Step: 0,1 % Range: 0,0 % - 200,0 % Freq int [ % ] Relative integration factor of frequency control loop. Step: 0 % – 100 % Range: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 87 [ % ] Gain of power control loop. Step: 0,1 % 0 – 200,0 % Range: Load int [ % ] Relative integration factor of power control loop. Step: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 88 SpeedRegOut behaviour for multi-gen-set applications Operation mode Island Parallel to mains Gen-set state Loaded island Loaded in parallel Running GCB closed Synchronizing GCB closed GCB opened MCB opened MCB closed Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 89: Volt/Pf Ctrl
0,0 to +200,0 % Voltage int [ % ] Relative integration factor of voltage control loop. Increasing of integration value causes quicker response. Step: 0 – 100 % Range: Hint: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 90 Loaded in parallel GCB opened GCB closed GCB closed MCB opened Active loop: Active loop: Active loop: Active loop: Volt gain, int; VS gain, int; Volt gain, int; PF control Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 91: Force Value
ExtValueX low limit. The value is not decreased under this limit, even if the request still exists (via binary input ExtValueX down). Step: -32000 – ExtValueXHiLim X Range: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 92: Load Shedding
ALL THE TIME Current Load Shedding works only according to gen-set Power, it works without reference to operation type (island, parallel or any transitions) Force value possibility: Yes Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 93 Step: Range: 0 - 600 s Force value: AutoLd recon [ DISABLED / ENABLED ] (FV) Switch between manual and automatic reconnection of shedded load. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 94: Timer Settings
So together with the Alarmlist content, the prefix of the Off load protection (“OfL” in English) is sent to indicate the reason for the active call (available in future SW versions). Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 95 Connected device type (Analog / GSM / ISDN / CDMA modem) is recognized automatically. AcallCH1..3-Addr Address for channel 1...3 active call. Each above message type has either a phone number or an e-mail address associated to it. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 96: Date/Time
WINTER (SUMMER) : Automatic switching between summer and wintertime is enabled and it is set to winter (summer) season. WINTER-S (SUMMER-S) : Modification for southern hemisphere. PremortHistPer [s] Range: [ 100ms – 200ms – 300ms – 1s – 3s] Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 97 #Time and #Date setpoints are synchronized via CAN bus each hour with the lowest address controller. #Time or #Date change in any controller changes Time or Date in all controllers on CAN bus. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 98: Table Of Values
Available in IS-NT only. Value: T Cyl min Group Engine values °C Units Related FW Description The value contains the minimus of all cylinder temperatures, i.e. maximum of all Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 99: Group: Gener Values
Generator active power in phase L2. Value: Act pwr L3 Group Gener values Units Related FW Description Generator active power in phase L3. Value: React power Group Gener values Units kVAr Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 100 Generator total apparent power. Value: Appar pwr L1 Group Gener values Units Related FW Description Generator apparent power in phase L1. Value: Appar pwr L2 Group Gener values Units Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 101 Generator power factor in phase L1. Value: Load char L1 Group Gener values Units Related FW Description Character of the generator load in the L1 phase. "L" means inductive load, "C" is Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 102 Value: Gen freq Group Gener values Units Related FW Description Generator frequency. The frequency is measured in the phase L3. Value: Gen V L1-N Group Gener values Units Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 103 The ratio between the voltage measured at the input terminals and the displayed voltage is adjusted by the setpoint ratio. Value: Gen V L1-L2 Group Gener values Units Related FW Description Generator voltage between phases L1 and L2. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 104 Generator current in phase L2. The ratio between the current measured at the input terminals and the displayed current is adjusted by the setpoints CT ratio prim CT ratio sec. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 105 "universal analog protections". Value: Slip freq Group Gener values Units Related FW Description Differential frequency between the generator and the mains/bus. Value: Angle Group Gener values ° Units Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 106: Group: Bus Values
The ratio between the voltage measured at the input terminals and the displayed voltage is adjusted by the setpoint Vb VT ratio. Value: Mains V L2-N Group Mains values Units Related FW Description Mains voltage in phase L2. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 107 Mains voltage. Average from all three phases. The ratio between the voltage measured at the input terminals and the displayed voltage is adjusted by the setpoint Vm VT ratio. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 108 Bus values Units Related FW Description Bus voltage phase L2 to L3. Value: Mains V L3-L1 Group Mains values Units Related FW Description Mains voltage phase L3 to L1. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 109: Group: Power Management
The ratio between the current measured at the input terminals and the displayed current is adjusted by the setpoints EarthFltCurCTp and Im3/ErFlCurCTs. Group: Power management Value: EnginePriority Group Pwr management Units Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 110 #LoadResStop plus Nominal power of the genset which is first to stop. #LoadResStop is used from the currently selected reserve set. Value: ActRes rel Group Power management Units Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 111 This status is valid for powermanagement with active Priority Auto Swap in EFFICIENT mode. The first bit from the left is assigned to address 1. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 112: Group: Sync/Load Ctrl
0% is sent for SpeedRegOut = -10V  100% is sent for SpeedRegOut = 10V Most of ECU units use the J1939 TSC1 frame for speed control, where the Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 113 Pwr management Units kVAr Related FW Description Sum of reactive power of all gen-sets within the group that are connected to the bus. Value: TotRunPact P Group Pwr management Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 114: Group: Volt/Pf Ctrl
Use GenConfig function Generate Cfg Image to get the communication object number or register number of this particular value object. Below is a typical example of using this object. XAMPLE Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 115 Use GenConfig function Generate Cfg Image to get the communication object number or register number of this particular value object. See an example at the object ExtValue1. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 116: Group: Load Shedding
Voltage at the controller power supply terminals. Value: CPU Temp Group Analog CU ºC Units Related FW Description Temperature inside the controller (on the CPU). Value: D+ Group Analog CU Units Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 117: Group: Bin Inputs Cu
In the default configuration the input is used for fuel level measurement. Group: Bin inputs CU Value: BIN Group Bin inputs CU Units Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 118: Group: Bin Outputs Cu
Click on button with "..." to get a clear list of BI names with their corresponding values. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 119 That means the bit 0 is displayed in the most left position. This is different from common use in computer science, where binary values are displayed from right to left. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 120 All terminals display binary values in "human-readable" form - from left to right. That means the bit 0 is displayed in the most left position. This is different from Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 121 “ModbusSw1..ModbusSw32”. No password is required for writing of those registers. There are two Values “ModbusSw1” and “ModbusSw2” in group “Log Bout” available for back-reading. Register for writing Modbus register number Value for back-reading Modbus register number Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 122: Group: Info
Code of the application type. E.g. 1 for SPtM, 2 for SPI, 3 for MINT etc. The value is intended for diagnostic purposes. Value: SW Branch Group Info Units Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 123 Bits of this value show "1" if the controller which has address corresponding with the bit position plays active role in the power management. Bit 0 represents address 1 etc. This value contains information about controllers with addresses 1- Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 124 "Type". The column "Type" contains reference to a list of codes and their representations located in the bottom part of the file. Value: Breaker state Group Info Units Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 125 This value contains date of next activation of the timer block 1-4 (i.e. of the output TimerAct 1-4). The related time is available in the value NextTime1-4. More information about timers is available in the chapter General purpose timers. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 126 Description This value contains date of next activation of the timer block 9-12 (i.e. of the output TimerAct 9-12). The related time is available in the value NextTime9-12. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 127 AirGate server this value displays the ID string assigned by the server. This ID string is to be used in ComAp PC tools (e.g. InteliMonitor) to specify the respective controller when the connection is opened. Value: AirGate status...
Page 128: Group: Statistics
IB-NT with active GPS. Time is automatically synchronized as well when succesfull GPS fix is established. If no valid value is available from InternetBridge-NT, value ##### is displayed. Group: Statistics Value: kWhours Group Statistics Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 129 The counter can be readjusted/reset from InteliMonitor menu Monitor -> Set statistics. Value: Service time 1 Group Statistics Units Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 130 It will be then decremented while the gen-set is running. The alarm WrnServiceTime is issued as soon as the timer counts down to zero. Value: TotalDownTime Group Statistics Units Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 131 Statistics Units Related FW This is the value of PulseCounter #2 module. See the binary input PulseCounter Description Available in IS-NT only. Value: PulseCounter 3 Group Statistics Units Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 132 Available in IS-NT only. Value: PulseCounter 4 Group Statistics Units Related FW Description This is the value of PulseCounter #4 module. See the binary input PulseCounter Available in IS-NT only. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 133: Table Of Binary Input Functions
This input is usually wired parallel into all controllers within the group to activate and deactivate all the gen-sets in the group by one switch (signal). If you want to Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 134 OFF mode only and GenConfig is not able to switch the controller to OFF mode while AUT mode is forced by this input. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 135 Use this input to disable temporarily the genset to be started e.g. from an higher- level automation device such as PLC. The genset will not be stopped if the input is activated while the genset is running. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 136 Maximal allowed time the both inputs are in the same position is 500ms, after this Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 137 The function of the input is identical as function of the horn reset button on the controller front panel. The input is enabled only if the setpoint Local Button is set to position EXTBUTTONS or BOTH. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 138 It is possible to use virtual peripheries for distribution of the binary signal from one physical switch connected to one controller to all other controllers over the CAN bus. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 139 All controllers cooperating together in Power management must have the same load reserve set selected. It is possible to use virtual peripheries for distribution of the binary signal from one Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 140 See the principial diagram of such distribution in the description of the input Load res Binary input: MinRun power 2 Related FW Description This input is used to activate the function Minimal running power #2, which is Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 141 These inputs are optional and if not configured, the priority is then adjusted by the setpoint Priority. NCODING TABLE RIORITY NPUT NPUT NPUT NPUT Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 142 These inputs are optional and if not configured, the priority is then adjusted by the setpoint Priority. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 143 1 and input pulses conter is reset to 0. Both counter value and input pulses counter are stored in the nonvolatile memory. The PulseCounter modules are intended e.g. for connecting external energy or fuel meters with pulse outputs. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 144 Minimal pulse width as well as minimal pause between two succesive pulses is 100ms. The counter value can be reset in the InteliMonitor statistics window. Available in IS-NT only. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 145 Binary input: Timer block 3 Related FW This input is used to disable temporarily the output from the Timer channel #3. Description See also the setpoint TimerChannel 3 and output TimerAct 1-4. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 146 This input is used to disable temporarily the output from the Timer channel #7. See also the setpoint TimerChannel 7 and output TimerAct 5-8. See the chapter Timers for more details about timers. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 147 Timers for more details about timers. Binary input: Timer block 12 Related FW Description This input is used to disable temporarily the output from the Timer channel #12. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 148 This input is used to disable temporarily the output from the Timer channel #16. See also the setpoint TimerChannel 16 and output TimerAct 13-16. See the chapter Timers for more details about timers. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 149 ExtValue2 rate until it reaches ExtValue2LoLim. If this input is used (configured), the ExtValue 2 can't be written remotely from a remote terminal using the command ExtValue 2. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 150 ExtValue4 rate until it reaches ExtValue4LoLim. If this input is used (configured), the ExtValue 4 can't be written remotely from a remote terminal using the command ExtValue 4. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 151 Configuring of the reset input does not block writing the ExtValue remotely, in comparison to the up and down inputs, which does. However, if the reset input is active, the remotely written data are not accepted. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 152 PLC functions to create the desired binary signal. 2. Configure an universal protection block to the binary signal mentioned Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 153 This input can be used to inform a remote user about a specific non-alarm situation, e.g. mains failure and/or mains return: 1. Select a binary signal in the controller, which indicates, that the particular Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 154 Description This input is used for connection of the normally open feedback contact from the Neutral contactor. If the input is active, the controller will consider the neutral Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 155 (i.e. the first active block according to the list displayed in GenConfig in the Force value window at the related setpoint). Watch a training video about force value function here: http://www.comap.cz/support/training/training-videos/. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 156 (i.e. the first active block according to the list displayed in GenConfig in the Force value window at the Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 157 Watch a training video about force value function here: http://www.comap.cz/support/training/training-videos/. See an example in the description of the binary input Force value Binary input: ForceValueIn 5 Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 158 (i.e. the first active block according to the list displayed in GenConfig in the Force value window at the related setpoint). Watch a training video about force value function here: http://www.comap.cz/support/training/training-videos/. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 159 Force value #10 block is configured, will be overriden by value of the alternative setpoint assigned to the Force value #10 block. If there are more than one force value blocks configured onto one setpoint then Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 160 GenConfig in the Force value window at the related setpoint). Watch a training video about force value function here: http://www.comap.cz/support/training/training-videos/. See an example in the description of the binary input Force value Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 161 (i.e. the first active block according to the list displayed in GenConfig in the Force value window at the related setpoint). Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 162 This is one of six binary inputs used for user-defined blocking of protections. If the input is active, all the protections that have Protection block type configured as Force block 3 block type are blocked (i.e. temporarily disabled). Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 163 Using these inputs for language selection is an option only. If the inputs are not configured, the language can be selected using the menus on the terminal. NCODING TABLE ANGUAGE INDEX NPUT NPUT NPUT Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 164 The reaction on changes of these inputs is delayed about 1 sec to ensure the new combination is valid (e.g. if a rotary selector switch is used). Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 165 Description This is one of three binary inputs Lang sel D#2 Lang sel D#2 Lang sel D#2 C, used for selecting language of the external local terminal #2. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 166 Using these inputs for language selection is an option only. If the inputs are not configured, the language can be selected using the menus on the terminal. NCODING TABLE ANGUAGE INDEX NPUT NPUT NPUT Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 167 "0" in the table means the input is not active or not configured. Language index 0 selects the default language of the terminal, i.e. the language, which is adjusted in the terminal using it's menus. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 168 (e.g. if a rotary selector switch is used). AUTION Each language change causes the reinitialization of the display. Function of the controller is not influenced. Binary input: Lang sel D#3 B Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 169 Using these inputs for language selection is an option only. If the inputs are not configured, the language can be selected using the menus on the terminal. NCODING TABLE ANGUAGE INDEX NPUT NPUT NPUT Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 170 E.g. this function can be used to "swap" between two different screen instruments when certain conditions are fulfilled. Logical binary inputs Mask 1..4 can be used to define any custom condition for this "swapping" function. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 171 Binary input: User mask 4 Related FW Description This input allows user to activate chosen function in ScreenEditor (tool for GenConfig) for particular screen instrument. User may choose from the following Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 172 GCB is closed. LBI: GCB open has higher priority, in case of activation LBI:GCB open – the LBI:GCB closed will be suppressed. Binary input: GCB open Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 173 Active: Generator starts unloading (according the ramp) and stays on zero load Deactivate: Generator is loading back according to ramp to require value from system This function does not control the breaker. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 174 Sync/Load ctrl. This function is used when there is no other genset to take over the load of the genset which is beeing unloaded. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 175: Table Of Analog Input Functions
The shared peripherial modules can be used to distribute the value over the controllers via the CAN2 bus. See the note in the description of the setpoint SysBaseLdMode. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 176 Analog input: Cyl temp 5 Related FW Logical analog input for cylinder temperature #5. Used for computing of values Description aver, T Cyl max, T Cyl min. Available in IS-NT only. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 177 Logical analog input for cylinder temperature #10. Used for computing of values aver, T Cyl max, T Cyl min. Available in IS-NT only. Analog input: Cyl temp 11 Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 178 T Cyl min. Available in IS-NT only. Analog input: Cyl temp 16 Related FW Description Logical analog input for cylinder temperature #16. Used for computing of values Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 179 Available in IS-NT only. Analog input: Cyl temp 21 Related FW Logical analog input for cylinder temperature #21. Used for computing of values Description aver, T Cyl max, T Cyl min. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 180 Analog input: Cyl temp 26 Related FW Description Logical analog input for cylinder temperature #26. Used for computing of values aver, T Cyl max, T Cyl min. Available in IS-NT only. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 181 Analog input: Cyl temp 31 Related FW Logical analog input for cylinder temperature #31. Used for computing of values Description aver, T Cyl max, T Cyl min. Available in IS-NT only. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 182 This analog input is intended for measuement of this thermocouple compensation Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 183 This analog input is intended for measuement of this thermocouple compensation temperature for the IS-AIN8 module with index #4. Thermocouples without internal compensation "Thermo(nc)..." must be used for this case. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 184: Table Of Binary Output Functions
LARM STATES AND BEHAVIOR OF RELATED OUTPUTS Binary output: Horn Related FW Description The output closes together with the output Alarm. It opens when the output Alarm Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 185 GCB has to be closed. There are also other outputs availabe for GCB control:  GCB ON coil  GCB OFF coil  GCB UV coil IMING OF BREAKER CONTROL OUTPUTS Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 186 Running phase follows after opening of the GCB (e.g. in MAN).  The output remains opened if the Cooling phase follows after opening of Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 187 Binary output: Syst res 1 OK Related FW Description The output is closed while the actual reserve is above the reserve for start from Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 188 The alarm Wrn SpdRegLim is disabled when this output is used (configured onto any controller terminal or virtual output). Binary output: Speed dn Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 189 Binary output: BO Vgen <> Related FW Description The output is closed while the generator over/under voltage alarm is present in the alarm list. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 190 The output is closed while there is at least one alarm of the Sensor fail type present in the alarm list. The alarm can be in any state, i.e. active unconfirmed, active confirmed or inactive unconfirmed.See the chapter Alarm management more information. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 191 The output is closed while there is at least one 1st level (yellow) alarm present in the alarm list. The alarm can be in any state, i.e. active unconfirmed, active confirmed or inactive unconfirmed. See the chapter Alarm management for more information. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 192 Learn more in the separate chapter Starting sequence. Binary output: FaultButnEcho Related FW Description This output provides 1s pulse when:  Fault reset button is pressed on the controller front panel or Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 193 Stop button is pressed on any of external local/remote terminals or  stop command is received via communication line or  the input StopButton is activated. Binary output: GCBButnEcho Related FW Description This output provides 1s pulse when: Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 194 This output indicates that the generator actually provides proper voltage and frequency. The output is closed while the gen-set is running (regardless of whether GCB is closed or not) and all generator electrical parameters are in limits. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 195 This LBO indicates that controller (or logical group, which the controller is member of) is connected to the mains. It means that there exists a way across MCB (IM- Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 196 Wrn NCB fail is issued. Learn more about neutral contactor in the description of the setpoint #Neutral cont.. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 197 ECU comm error present in the alarm list. Binary output: PeriphCommErr Related FW Description The output is closed while there is an error in the communication with any Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 198 This output is used for control of first load group. This is the group which is disconnected as first one when the load shedding function becomes active. Connect least important loads to this group. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 199 Binary output: TimerAct 9-12 Related FW Description This is combined output from timer channels 9-12. The output is closed if at least one of the channels is active. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 200 Remote AUT). Binary output: SystReady Related FW Description The output is closed while the group of gen-sets has enough capacity to fulfil the Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 201 The output is closed while:  the genset is not running and  the controller is in OFF mode or  there is an alarm blocking start of the gen-set. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 202 Binary output: Soft unld Related FW Description The output is closed while the gen-set is beeing unloaded before opening GCB. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 203 Pressing the button changes the state of log. binary output User Button X to opened. When the output is opened and the button is pressed state is not changed. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 204 It is possible to lock UserButton commands in configuration to specific user level. Buttons 1-8 and 9-16 are locked separately. Pressing the button changes the state of log. binary output User Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 205 Related FW Description This output can be specified for example on buttons on IV-5/8 or in SCADA diagram in InteliMonitor. Its state depends on function assigned to the related Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 206 Repeated pressing of button during the closed period (one second) causes issuing another puls of length of one second to be generated from the moment of button pushing. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 207 Pressing the button issues log. binary output User Button X to ULSE close for one second. Repeated pressing of button during the closed period (one Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 208 Button X to opened. When the output is opened and the button is pressed state is not changed. ON/OFF Pressing the button changes the state of log. binary output User Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 209 Buttons 1-8 and 9-16 are locked separately. Pressing the button changes the state of log. binary output User Button X to closed. When the output is closed and the button is Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 210 Description This output can be specified for example on buttons on IV-5/8 or in SCADA diagram in InteliMonitor. Its state depends on function assigned to the related button. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 211 Repeated pressing of button during the closed period (one second) causes issuing another puls of length of one second to be generated from the moment of button pushing. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 212 See the Remote switches chapter in the InteliMonitor help for details about how to control the output from InteliMonitor and the Modbus chapter in the latest communication guide for information about control the output using Modbus. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 213 See the Remote switches chapter in the InteliMonitor help for details about how to control the output from InteliMonitor and the Modbus chapter in the latest communication guide for information about control the output using Modbus. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 214 The output is closed while there is the ECU alarm present in the alarm list, i.e. if Description an ECU unit is configured and it does not communicate with the controller althought it is required to communicate. Alarm output: SHBinCfgErr Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 215 The controller is in situation, when the load sharing should beeing performed, however there is not any dongle with "LS" feature inserted in the controller. Alarm output: Emergency stop Related FW Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 216 This alarm is disabled when speed governing via binary outputs Speed up Speed dn is used (i.e. at least one of these outputs is configured onto a physical Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 217 The output is closed while the alarm generated by the PLC block Force prot 2 is present in the alarm list. The actual text, which appears in the alarm list, can be changed in GenConfig. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 218 Bus voltages are In synchronism – according to condition based on setpoints: - Voltage window - Phase window - Dwell time Hint: In MAN mode, function Gen sync=1 does nothing, just causes possibility to Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 219 This LBO detects that regulation of load sharing and VARr sharing are running based on droop (setpoint Reg kW/kVAr is set to DROOP or to EMERG DROOP and emergency droop is active or the LBI kVArDroopAct). Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 220 (outputs of Delays in the controller are activated immediately during the power on if Delay input is active prior and during the power up). Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 221: Controller Configuration And Monitoring
 Configure Binary outputs  Configure Analog inputs as Protection or Function  Define user sensors  Configure History record  Configure password protection  Add/Translate the language Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...
Page 222: Intelimonitor
It is possible to export actual values, setpoints and history file on-line from the controller or off-line from the archive using InteliMonitor – Monitor – Export data… function. Technical data Hint: Technical data of the controller and extension modules find in the IGS-NT-Installation guide-x.y.pdf. Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015 IGS-NT-GeCon-MARINE-MINT-3.2.PDF...

This manual is also suitable for:

Ig-nt-bb Ig-ntc-bb Ig-ntc gc Is-nt Is-ntc-bb
