Modified setpoints

Below mentioned are GeCon specific setpoints only.
Group Setpoint
Process control StartStopBtn
ProtectionMode
Sync/Load ctrl Sync timeout
GCB open level
GCB open del
Hint:
All above mentioned setpoints can be Forced by Binary input(s) to another value (or switched between
ENABLED and DISABLED).
Based on setpoint settings there are three possible operational modes HAND – SEM - AUT:
Basic setting ControllerMode
Process control StartStopBtn
ProtectionMode
Sync/Load ctrl Sync timeout
GCB open level
GCB open del
Hint:
It is possible to configure (Force value) "HAND" – SEM switching via Binary input.
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
Option Function
ENABLED Standard panel Start/Stop buttons function.
DISABLED Panel Start/Stop buttons are disabled.
ACTIVE ACTIVE:
NOT ACTIVE 2-nd level protections are evaluated, GCB
or MCB is controlled.
NOT ACTIVE:
2-nd level protections are evaluated, GCB
or MCB is NOT opened.
Exceptions are Emerg Stop and alarms
types Sdoverride.
1-1800s Standard MINT function.
NO TIMEOUT Unlimited synchronizing time.
1-100% Standard MINT function.
NO LEVEL No generator power open level detection.
1-1800s Standard MINT function.
NO TIMEOUT Unlimited unloading procedure.
"HAND"
SEM
SEM SEM
DISABLED ENABLED
NOT ACTIVE ACTIVE
/ACTIVE
NO TIMEOUT 1-1800s
NO LEVEL 1-100%
NO TIMEOUT 1-1800s
AUT
AUT
ENABLED
ACTIVE
1-1800s
1-100%
1-1800s
