Function is active in any controller mode and activation of this input is written to
history.
Binary input: ManualLdRecon
Related FW 3.2
Description This input is used for manual reconnection of the last disconnected part of the
load, if the load has dropped below the setpoint
This input works only if automatic reconnection is disabled, i.e. the setpoint
AutoLd recon
Binary input: FaultResButton
Related FW 3.2
Description This input is used for an external FAULT RESET button mounted on the
switchboard. The function of the input is identical as function of the fault reset
button on the controller front panel.
The input is enabled only if the setpoint
EXTBUTTONS or BOTH.
Binary input: HornResButton
Related FW 3.2
Description This input is used for an external HORN RESET button mounted on the
switchboard. The function of the input is identical as function of the horn reset
button on the controller front panel.
The input is enabled only if the setpoint
EXTBUTTONS or BOTH.
Binary input: StopButton
Related FW 3.2
Description This input is used for an external STOP button mounted on the switchboard. The
function of the input is identical as function of the stop button on the controller
front panel.
The input is enabled only if the setpoint
EXTBUTTONS or BOTH.
Binary input: StartButton
Related FW 3.2
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
is set to DISABLED.
Ld recon level.
Local Button is set to position
Local Button is set to position
Local Button is set to position
