ComAp IG-NT GC Reference Manual page 145

Description This input is used for an external START button mounted on the switchboard. The
function of the input is identical as function of the start button on the controller
front panel.
The input is enabled only if the setpoint
EXTBUTTONS or BOTH.
Binary input: GCBButton
Related FW 3.2
Description This input is used for an external GCB button mounted on the switchboard. The
function of the input is identical as function of the GCB button on the controller
front panel.
The input is enabled only if the setpoint
EXTBUTTONS or BOTH.
Binary input: ECUComFailBlck
Related FW 3.2
Description The input disables issuing of the ECU communication failure alarm and all other
alarms related to values that are being read from the ECU.
Binary input: PulseCounter 1
Related FW 3.2
This is the input of the PulseCounter #1 module. The module counts pulses at the
Description
input and if the input pulses counter reaches value given by the setpoint
ConvCoefPulse1, the counter value
increased by 1 and input pulses conter is reset to 0. Both counter value and input
pulses counter are stored in the nonvolatile memory.
The PulseCounter modules are intended e.g. for connecting external energy or
fuel meters with pulse outputs.
N
OTE
Minimal pulse width as well as minimal pause between two succesive pulses is
100ms.
N
OTE
The counter value can be reset in the InteliMonitor statistics window.
Binary input: PulseCounter 2
Related FW 3.2
Description This is the input of the PulseCounter #2 module. The module counts pulses at the
input and if the input pulses counter reaches value given by the setpoint
ConvCoefPulse2, the counter value
increased by 1 and input pulses conter is reset to 0. Both counter value and input
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
:
:
Local Button is set to position
Local Button is set to position
PulseCounter 1 (in the group Statistic) is
PulseCounter 2 (in the group Statistic) is
145
