pulses counter are stored in the nonvolatile memory.
The PulseCounter modules are intended e.g. for connecting external energy or
fuel meters with pulse outputs.
N
OTE
Minimal pulse width as well as minimal pause between two succesive pulses is
100ms.
N
OTE
The counter value can be reset in the InteliMonitor statistics window.
N
OTE
Available in IS-NT only.
Binary input: PulseCounter 3
Related FW 3.2
Description This is the input of the PulseCounter #3 module. The module counts pulses at the
input and if the input pulses counter reaches value given by the setpoint
ConvCoefPulse3, the counter value
increased by 1 and input pulses conter is reset to 0. Both counter value and input
pulses counter are stored in the nonvolatile memory.
The PulseCounter modules are intended e.g. for connecting external energy or
fuel meters with pulse outputs.
N
OTE
Minimal pulse width as well as minimal pause between two succesive pulses is
100ms.
N
OTE
The counter value can be reset in the InteliMonitor statistics window.
N
OTE
Available in IS-NT only.
Binary input: PulseCounter 4
Related FW 3.2
Description This is the input of the PulseCounter #4 module. The module counts pulses at the
input and if the input pulses counter reaches value given by the setpoint
ConvCoefPulse4, the counter value
increased by 1 and input pulses conter is reset to 0. Both counter value and input
pulses counter are stored in the nonvolatile memory.
The PulseCounter modules are intended e.g. for connecting external energy or
fuel meters with pulse outputs.
N
OTE
Minimal pulse width as well as minimal pause between two succesive pulses is
100ms.
N
OTE
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
:
:
:
:
:
:
:
:
PulseCounter 3 (in the group Statistic) is
PulseCounter 4 (in the group Statistic) is
