ComAp IG-NT GC Reference Manual page 174

Binary input: ReadyToLoad
Related FW 3.2
Description This input is determinated for signal from Engine unit. This Input indicates that
engine unit is ready for Load.
When the input is deactivated then the GCB is opened.
When this input is activated then Min Stab Time start is counted down.
Binary input: GCB close
Related FW 3.2
Description This input is determinated for safety hand control in SEM mode.
LBI: GCB close is accepted in SEM mode when LBI:ReadyToLoad=1 ,there are
no alarms 2nd level in alarmlist and Gen voltage and frequency are in limits .
N
OTE
LBI: GCB open has higher priority, in case of activation LBI:GCB open – the
LBI:GCB closed will be suppressed.
Binary input: GCB open
Related FW 3.2
Description This input is determinated for safety hand control in SEM mode.
LBI: GCB close is accepted in SEM mode when LBI:ReadyToLoad=1.
N
OTE
LBI: GCB open has higher priority, in case of activation LBI:GCB open – the
LBI:GCB closed will be suppressed.
Binary input: Gen sync
Related FW 3.2
Description This input is determinated for activation Synchronisation process, supported in
SEM mode only.
LBI:Gen sync = 1 – regulations for synchronisation are activated.
LBI:Gen sync = 0 – regulations for synchronisation are deactivated.
This function is designed for holding the generator In synchronism (according
phase and voltage limits –set by setpoints).
Synchronisation process is active during time set by Setpoint Sync timeout
(Sync/Load ctrl group).
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
In case of no voltage on BUS bar – GCB is closed.
-
In case of correct voltage and frequency on the bus – Synchronisation is
-
activated and subsequently GCB is closed.
:
:
