ComAp IG-NT GC Reference Manual page 154

N
OTE
Configuring of the reset input does not block writing the ExtValue remotely, in
comparison to the up and down inputs, which does. However, if the reset input is
active, the remotely written data are not accepted.
Binary input: IssueActCallC1
Related FW 3.2
Description This input forces the controller to issue an active call/e-mail/SMS via the channel
#1. Type of the channel is to be adjusted by the setpoint AcallCH1-Type.
This input can be used to inform a remote user about a specific non-alarm
situation, e.g. mains failure and/or mains return:
Binary input: IssueActCallC2
Related FW 3.2
Description This input forces the controller to issue an active call/e-mail/SMS via the channel
#2. Type of the channel is to be adjusted by the setpoint AcallCH2-Type.
This input can be used to inform a remote user about a specific non-alarm
situation, e.g. mains failure and/or mains return:
Binary input: IssueActCallC3
Related FW 3.2
Description This input forces the controller to issue an active call/e-mail/SMS via the channel
#3. Type of the channel is to be adjusted by the setpoint AcallCH3-Type.
This input can be used to inform a remote user about a specific non-alarm
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
remote terminal using the ExtValue command.
:
1. Select a binary signal in the controller, which indicates, that the particular
situation occured, about which you want to be informed remotely. There
are many predefined binary informations provided directly by the
controller or use PLC functions to create the desired binary signal.
2. Configure an universal protection block to the binary signal mentioned
above and select protection type AL indication.
3. Configure the binary signal mentioned above onto the logical binary input
IssueActCallC1.
1. Select a binary signal in the controller, which indicates, that the particular
situation occured, about which you want to be informed remotely. There
are many predefined binary informations provided directly by the
controller or use PLC functions to create the desired binary signal.
2. Configure an universal protection block to the binary signal mentioned
above and select protection type AL indication.
3. Configure the binary signal mentioned above onto the logical binary input
IssueActCallC2.
