CANAddrSwitch1
The setpoint selects function of the terminal address 122 at the CAN2 line. See the latest communication
guide for details about this topic.
MODEM The address is used for modem connection via I-LB
OTHER The address is used for direct connection to any other device as e.g. IV8 or I-RD.
CANAddrSwitch2
The setpoint selects function of the terminal address 125 at the CAN2 line. See the latest communication
guide for details about this topic.
MODEM The address is used for modem connection via I-LB
OTHER The address is used for direct connection to any other device as e.g. IV8 or I-RD
IP address

In fixed settings mode
controller. Ask your IT specialist for help with this setting.

In Automatic settings mode
by the DHCP server. It is not possible to change the setpoint value manually in this setting (the value
is immediately reverted back by controller communication module IB-COM).
IP Addr mode
The setpoint is used to select the method how the ethernet connection is adjusted.
FIXED The ethernet connection is adjusted fixedly according to the setpoints
mask, Gateway
This method should be used for classic ethernet or
of connection is opening the controller is specified by it's IP address. That means it
would be inconvenient if the IP address were not fixed (static).
AUTOMATIC The ethernet connection settings is obtained automatically from the DHCP server.
The obtained settings is then copied to the related setpoints (it is not possible to set
those setpoints manually in this setting, for more information please see the following
setpoints:
the settings from DHCP server is not successful the value 000.000.000.000 is copied to
the setpoint
This method is beneficial for
in fact "plug and play". When this type of connection is opening the controller is
specified by it's AirGate ID and the IP address does not play any role.
C !
AUTION
If you need to use fixed ethernet settings you should consult the proper setting with your IT specialist.
Inteli NT GeCon-MARINE SPI, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-SPI-3.2.PDF
this setpoint is used to adjust the IP address of the ethernet interface of the
this setpoint is used to display the IP address, which has been assigned
IP, DNS IP. .
IP address, Net mask, Gateway IP
IP address and the module continues trying to obtain the settings.
AirGate connection
Internet connection. When this type
and DNS IP). If the process of obtaining
as it makes the connection very easy,
IP address, Net
