UNIVERGE SV8100
Input Data
Item Name
01
Detect Level
02 Start delay time
03 Min. detect level
04 Max. detect level
05 twist level
06 S/N ratio
07 ON detect time
08 OFF detect time
Feature Cross Reference
None
SV8100 Programming Manual
Item
Item
No.
04 Max. detect level
05 Twist level
06 S/N ratio
07 ON detect time
08 OFF detect time

Table 2-19 Default Table

Type 1
0
0
10 (-20dBm)
2 (-2dBm)
5 (6dBm)
2 (-10dBm)
1 (30ms)
1 (30ms)
Conditions
None
0~15
MF Tone 1 : -5dBm(0) to -20dBm(15)
MF Tone 2 : -10dBm(0) to -25dBm(15)
MF Tone 3 : -15dBm(0) to -30dBm(15)
MF Tone 4 : -20dBm(0) to -35dBm(15)
MF Tone 5 : -25dBm(0) to -40dBm(15)
MF Tone 6 : -30dBm(0) to -45dBm(15)
0~9 (1dB~10dB)
0~4 (-5step, 0dB~ -20dB)
1~255 (15step, 30ms~3840ms)
1~255 (15step, 30ms~3840ms)
Type 2 Type 3
0 0
0 0
10 (-20dBm) 10 (-20dBm)
2 (-2dBm) 2 (-2dBm)
5 (6dBm) 5 (6dBm)
2 (-10dBm) 2 (-10dBm)
1 (30ms) 1 (30ms)
1 (30ms) 1 (30ms)
Input Data
Type 4
0
0
10 (-20dBm) 10 (-20dBm)
2 (-2dBm) 2 (-2dBm)
5 (6dBm) 5 (6dBm)
2 (-10dBm) 2 (-10dBm)
1 (30ms) 1 (30ms)
1 (30ms) 1 (30ms)
Issue 11.0
Type 5
0
0
2 - 677
